Nanostructured Optical Devices Laboratory, Electric and Electronic Engineering Department, Public University of Navarra, Edif,Los Tejos, Campus Arrosadía, 31006, Pamplona, Spain.
Nanoscale Res Lett. 2013 Oct 22;8(1):438. doi: 10.1186/1556-276X-8-438.
In the present study, we show that silver nanoparticles (AgNPs) with different shape, aggregation state and color (violet, green, orange) have been successfully incorporated into polyelectrolyte multilayer thin films using the layer-by-layer (LbL) assembly. In order to obtain colored thin films based on AgNPs is necessary to maintain the aggregation state of the nanoparticles, a non-trivial aspect in which this work is focused on. The use of Poly(acrylic acid, sodium salt) (PAA) as a protective agent of the AgNPs is the key element to preserve the aggregation state and makes possible the presence of similar aggregates (shape and size) within the LbLcolored films. This approach based on electrostatic interactions of the polymeric chains and the immobilization of AgNPs with different shape and size into the thin films opens up a new interesting perspective to fabricate multicolornanocomposites based on AgNPs.
在本研究中,我们展示了不同形状、聚集状态和颜色(紫色、绿色、橙色)的银纳米粒子(AgNPs)已经成功地通过层层(LbL)组装技术被整合到聚电解质多层薄膜中。为了获得基于 AgNPs 的有色薄膜,有必要保持纳米粒子的聚集状态,这是这项工作的重点。使用聚(丙烯酸,钠盐)(PAA)作为 AgNPs 的保护剂是保持聚集状态的关键因素,并使相似的聚集物(形状和大小)在 LbL 彩色薄膜中成为可能。这种基于聚合物链的静电相互作用以及不同形状和尺寸的 AgNPs 固定在薄膜中的方法为制备基于 AgNPs 的多色纳米复合材料开辟了一个新的有趣视角。
