Shenyang National Laboratory for Materials Science, Institute of Metal Research, Chinese Academy of Sciences, 72 Wenhua Road, Shenyang, 110016, China.
Department of Materials Science and Engineering, Johns Hopkins University, Baltimore, MD, 21218, USA.
Sci Rep. 2017 Sep 8;7(1):11053. doi: 10.1038/s41598-017-11504-6.
Salt-fluxing treatment is an effective technique to improve the glass-forming ability (GFA) of bulk metallic glass (BMG)-forming melts, as demonstrated before in Pd- and Fe-based systems. However, it has been challenging to develop similar fluxing protocol for more reactive melts, such as Al-rich BMG-forming systems. Here we design new fluxing agents, from a thermodynamics perspective that takes into account combined effects of physical absorption and chemical absorption (reaction) between the fluxing agents and oxide inclusions. MgCl-CaCl composite salts were selected, and their fluxing effects were systematically studied on an AlNiCoYLa alloy, the best BMG-forming composition reported thus far for Al-rich alloy systems. The oxygen content was found to continuously decrease in the master alloy with increasing cycles of salt-fluxing treatment, with chlorate products on the surface suggesting concurrent physical absorption and chemical reaction. The fluxing treatment developed has enabled a record critical size (diameter) of 2.5 mm for Al-based BMGs. Our finding is thus an advance in developing highly desirable Al-based BMGs, and also provides guidance for designing processing protocol to produce larger-sized BMGs in other reactive systems.
盐通量处理是一种提高大块金属玻璃(BMG)形成熔体形成能力(GFA)的有效技术,以前在 Pd 和 Fe 基系统中已经得到了证明。然而,对于更具反应性的熔体,如富含 Al 的 BMG 形成系统,开发类似的通量处理协议一直具有挑战性。在这里,我们从热力学的角度设计了新的通量处理剂,考虑了通量处理剂与氧化物夹杂物之间的物理吸收和化学吸收(反应)的综合效应。选择了 MgCl-CaCl 复合盐,并在 AlNiCoYLa 合金上系统地研究了它们的通量处理效果,这是迄今为止报道的富 Al 合金系统中最好的 BMG 形成成分。随着盐通量处理循环次数的增加,发现母合金中的氧含量不断降低,表面上出现氯酸盐产物表明存在物理吸收和化学反应的同时发生。所开发的通量处理技术使 Al 基 BMG 的临界尺寸(直径)达到了 2.5mm 的记录。因此,我们的发现是在开发高期望的 Al 基 BMG 方面的一项进展,也为在其他反应性系统中生产更大尺寸 BMG 提供了设计处理方案的指导。
