Esteban Oscar, Birman Daniel, Schaer Marie, Koyejo Oluwasanmi O, Poldrack Russell A, Gorgolewski Krzysztof J
Department of Psychology, Stanford University, Stanford, California, United States of America.
Department of Psychiatry, University of Geneva School of Medicine, Geneva, Switzerland.
PLoS One. 2017 Sep 25;12(9):e0184661. doi: 10.1371/journal.pone.0184661. eCollection 2017.
Quality control of MRI is essential for excluding problematic acquisitions and avoiding bias in subsequent image processing and analysis. Visual inspection is subjective and impractical for large scale datasets. Although automated quality assessments have been demonstrated on single-site datasets, it is unclear that solutions can generalize to unseen data acquired at new sites. Here, we introduce the MRI Quality Control tool (MRIQC), a tool for extracting quality measures and fitting a binary (accept/exclude) classifier. Our tool can be run both locally and as a free online service via the OpenNeuro.org portal. The classifier is trained on a publicly available, multi-site dataset (17 sites, N = 1102). We perform model selection evaluating different normalization and feature exclusion approaches aimed at maximizing across-site generalization and estimate an accuracy of 76%±13% on new sites, using leave-one-site-out cross-validation. We confirm that result on a held-out dataset (2 sites, N = 265) also obtaining a 76% accuracy. Even though the performance of the trained classifier is statistically above chance, we show that it is susceptible to site effects and unable to account for artifacts specific to new sites. MRIQC performs with high accuracy in intra-site prediction, but performance on unseen sites leaves space for improvement which might require more labeled data and new approaches to the between-site variability. Overcoming these limitations is crucial for a more objective quality assessment of neuroimaging data, and to enable the analysis of extremely large and multi-site samples.
磁共振成像(MRI)的质量控制对于排除有问题的采集以及避免后续图像处理和分析中的偏差至关重要。目视检查具有主观性,对于大规模数据集而言不切实际。尽管已经在单站点数据集上证明了自动化质量评估,但尚不清楚这些解决方案能否推广到在新站点采集的未见数据。在此,我们介绍MRI质量控制工具(MRIQC),这是一种用于提取质量指标并拟合二元(接受/排除)分类器的工具。我们的工具既可以在本地运行,也可以通过OpenNeuro.org门户作为免费在线服务运行。该分类器在一个公开可用的多站点数据集(17个站点,N = 1102)上进行训练。我们进行模型选择,评估旨在最大化跨站点泛化的不同归一化和特征排除方法,并使用留一站点交叉验证估计在新站点上的准确率为76%±13%。我们在一个保留数据集(2个站点,N = 265)上确认了该结果,准确率同样为76%。尽管训练后的分类器性能在统计学上高于随机水平,但我们表明它易受站点效应影响,无法解释新站点特有的伪影。MRIQC在站点内预测中表现出高精度,但在未见站点上的性能仍有改进空间,这可能需要更多标记数据和针对站点间变异性的新方法。克服这些限制对于更客观地评估神经影像数据以及分析极大型和多站点样本至关重要。
