厚度控制和界面修饰在组装高效平面钙钛矿太阳能电池中的作用。

The Role of Thickness Control and Interface Modification in Assembling Efficient Planar Perovskite Solar Cells.

机构信息

Institute for Materials Discovery, University College London, London WC1E 7JE, UK.

State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China.

出版信息

Molecules. 2019 Sep 24;24(19):3466. doi: 10.3390/molecules24193466.

Abstract

Perovskite solar cells (PSCs) have achieved tremendous success within just a decade. This success is critically dependent upon compositional engineering, morphology control of perovskite layer, or contingent upon high-temperature annealed mesoporous TiO, but quantitative analysis of the role of facile TiCl treatment and thickness control of the compact TiO layer has not been satisfactorily undertaken. Herein, we report the facile thickness control and post-treatment of the electron transport TiO layer to produce highly efficient planar PSCs. TiCl treatment of TiO layer could remove the surface trap and decrease the charge recombination in the prepared solar cells. Introduction of ethanol into the TiCl aqueous solution led to further improved open-circuit voltage and short-circuit current density of the related devices, thus giving rise to enhanced power conversion efficiency (PCE). After the optimal TiCl treatment, PCE of 16.42% was achieved for PSCs with TiCl aqueous solution-treated TiO and 19.24% for PSCs with TiCl aqueous/ethanol solution-treated TiO, respectively. This work sheds light on the promising potential of simple planar PSCs without complicated compositional engineering and avoiding the deposition and optimization of the mesoporous scaffold layer.

摘要

钙钛矿太阳能电池(PSCs)在短短十年内取得了巨大的成功。这一成功在很大程度上取决于组成工程、钙钛矿层的形态控制,或者依赖于高温退火的介孔 TiO,但对易于进行的 TiCl 处理和致密 TiO 层厚度控制的作用的定量分析尚未得到令人满意的研究。在此,我们报告了易于控制致密 TiO 层的厚度并对其进行后处理,以制备高效的平面 PSCs。TiCl 处理 TiO 层可以去除表面陷阱并减少制备的太阳能电池中的电荷复合。将乙醇引入 TiCl 水溶液中,导致相关器件的开路电压和短路电流密度进一步提高,从而提高了功率转换效率(PCE)。经过最佳的 TiCl 处理,TiCl 水溶液处理的 TiO 平面 PSCs 的 PCE 达到 16.42%,TiCl 水溶液/乙醇溶液处理的 TiO 平面 PSCs 的 PCE 达到 19.24%。这项工作为简单的平面 PSCs 提供了有前景的潜力,而无需复杂的组成工程,并且避免了介孔支架层的沉积和优化。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/f3a7/6803942/d5f063bf2332/molecules-24-03466-g001.jpg
