Effects of Shape Anisotropy on Hard-Soft Exchange-Coupled Permanent Magnets.

Exchange-coupled magnets are promising candidates for a new generation of permanent magnets. Here, we investigated the effect of soft magnetic shell thickness and the aspect ratio of the hard magnetic core on the magnetic properties for isolated core/shell cylinder exchange-coupled magnets, as well as the packing effect of the cylindrical array via a micromagnetic simulation method. It was found that the shape anisotropy contributions to the magnetic properties in the cylindrical core/shell exchange-coupled magnets are closely related to the thickness of the soft magnetic shell. When the soft magnetic shell is thin, the magnetic properties are dominated by the hard-soft exchange coupling effects, and the contributions of shape anisotropy are quite limited. When the soft magnetic shell is relatively thick, utilizing shape anisotropy would be an effective method to improve the magnetic performance of hard-soft exchange-coupled magnets. The present work provides an in-depth fundamental understanding of the underlying magnetization reversal mechanism. This work could be useful for designing high-performance permanent magnets and avoiding pitfalls.
