Valencia Luisa M, Herrera Miriam, de la Mata María, Hernández-Saz Jesús, Romero-Ocaña Ismael, Delgado Francisco J, Benito Javier, Molina Sergio I
Departamento de Ciencia de los Materiales e Ingeniería Metalúrgica y Química Inorgánica, IMEYMAT, Facultad de Ciencias, Universidad de Cádiz, Campus Río San Pedro, s/n, 11510 Cádiz, Spain.
Departamento de Ingeniería y Ciencia de los Materiales y del Transporte, Universidad de Sevilla, Avda. Camino de los Descubrimientos s/n, 41092 Sevilla, Spain.
Polymers (Basel). 2022 Dec 1;14(23):5238. doi: 10.3390/polym14235238.
Polymer nanocomposites (PNCs) attract the attention of researchers and industry because of their potential properties in widespread fields. Specifically, electrically conductive and semiconductor PNCs are gaining interest as promising materials for biomedical, optoelectronic and sensing applications, among others. Here, metallic nanoparticles (NPs) are extensively used as nanoadditives to increase the electrical conductivity of mere acrylic resin. As the in situ formation of metallic NPs within the acrylic matrix is hindered by the solubility of the NP precursors, we propose a method to increase the density of Ag NPs by using different intermediate solvents, allowing preparation of Ag/acrylic resin nanocomposites with improved electrical behaviour. We fabricated 3D structures using stereolithography (SLA) by dissolving different quantities of metal precursor (AgClO) in methanol and in ,-dimethylformamide (DMF) and adding these solutions to the acrylic resin. The high density of Ag NPs obtained notably increases the electrical conductivity of the nanocomposites, reaching the semiconductor regime. We analysed the effect of the auxiliary solvents during the printing process and the implications on the mechanical properties and the degree of cure of the fabricated nanocomposites. The good quality of the materials prepared by this method turn these nanocomposites into promising candidates for electronic applications.
聚合物纳米复合材料(PNCs)因其在广泛领域的潜在性能而吸引了研究人员和工业界的关注。具体而言,导电和半导体PNCs作为生物医学、光电和传感等应用的有前途的材料正受到越来越多的关注。在这里,金属纳米颗粒(NPs)被广泛用作纳米添加剂以提高纯丙烯酸树脂的电导率。由于NP前体的溶解度阻碍了丙烯酸基质中金属NP的原位形成,我们提出了一种使用不同中间溶剂来增加Ag NPs密度的方法,从而制备出具有改善电学性能的Ag/丙烯酸树脂纳米复合材料。我们通过立体光刻(SLA)制造3D结构,将不同量的金属前体(AgClO)溶解在甲醇和N,N-二甲基甲酰胺(DMF)中,并将这些溶液添加到丙烯酸树脂中。所获得的高密度Ag NPs显著提高了纳米复合材料的电导率,达到了半导体状态。我们分析了印刷过程中辅助溶剂的影响以及对所制备纳米复合材料的机械性能和固化程度的影响。通过这种方法制备的材料质量良好,使这些纳米复合材料成为电子应用的有前途的候选材料。
