Optical Protective Window Design and Material Selection Issues in the Multi-Sensor Electro-Optical Surveillance Systems.

Multi-sensor imaging systems have a very important role and wide applications in surveillance and security systems. In many applications, it is necessary to use an optical protective window as an optical interface connecting the imaging sensor and object of interest's space; meanwhile an imaging sensor is mounted in a protective enclosure, providing separation from environmental conditions. Optical windows are often used in various optical and electro-optical systems, fulfilling different sometimes very unusual tasks. There are lots of examples in the literature that define optical window design for targeted applications. Through analysis of the various effects that follow optical window application in connection with imaging systems, we have suggested a simplified methodology and practical recommendation for how to define optical protective window specifications in multi-sensor imaging systems, using a system engineering approach. In addition, we have provided initial set of data and simplified calculation tools that can be used in initial analysis to provide proper window material selection and definition of the specifications of optical protective windows in multi-sensor systems. It is shown that although the optical window design seems as a simple task, it requires serious multidisciplinary approach.
