Thermal inspection for viscous dissipation slip flow of hybrid nanofluid (TiO-AlO/CHO) using cylinder, platelet and blade shape features.

Hybrid nanofluid are the modified class of nanofluids with extra high thermal performances and present different applications in automotive cooling, heat transfer devices, solar collectors, engine applications, fusion processes, machine cutting, chemical processes etc. This thermal research explores the heat transfer assessment due to hybrid nanofluid with of different shape features. The thermal inspections regarding the hybrid nanofluid model are justified with aluminium oxide and titanium nanoparticles. The base liquid properties are disclosed with ethylene glycol material. The novel impact of current model is the presentation of different shape features namely Platelets, blade and cylinder. Different thermal properties of utilized nanoparticles at various flow constraints are reported. The problem of hybrid nanofluid model is modified in view of slip mechanism, magnetic force and viscous dissipation. The heat transfer observations for decomposition of TiO-AlO/CHO is assessed by using the convective boundary conditions. The shooting methodology is involved for finding the numerical observations of problem. Graphical impact of thermal parameters is observed for TiO-AlO/CHO hybrid decomposition. The pronounced observations reveal that thermal rate enhanced for blade shaped titanium oxide-ethylene glycol decomposition. The wall shear force reduces for blade shaped titanium oxide nanoparticles.
