Interference recommendation for the pump sizing process in progressive cavity pumps using graph neural networks.

Pump sizing is the process of dimensional matching of an impeller and stator to provide a satisfactory performance test result and good service life during the operation of progressive cavity pumps. In this process, historical data analysis and dimensional monitoring are done manually, consuming a large number of man-hours and requiring a deep knowledge of progressive cavity pump behavior. This paper proposes the use of graph neural networks in the construction of a prototype to recommend interference during the pump sizing process in a progressive cavity pump. For this, data from different applications is used in addition to individual control spreadsheets to build the database used in the prototype. From the pre-processed data, complex network techniques and the betweenness centrality metric are used to calculate the degree of importance of each order confirmation, as well as to calculate the dimensionality of the rotors. Using the proposed method a mean squared error of 0.28 is obtained for the cases where there are recommendations for order confirmations. Based on the results achieved, it is noticeable that there is a similarity of the dimensions defined by the project engineers during the pump sizing process, and this outcome can be used to validate the new design definitions.
