Schroyer Kaitlyn Ann Rose, Schmitz Kylie Marie, Raheja Gunjeeta, Su Bin, Lathia Justin D, Ning Liqun
Department of Chemical and Biomedical Engineering, Cleveland State University, Cleveland, OH 44115, USA.
Department of Mechanical Engineering, Cleveland State University, Cleveland, OH 44115, USA.
Micromachines (Basel). 2025 May 29;16(6):654. doi: 10.3390/mi16060654.
Glioblastoma (GBM, isocitrate dehydrogenase wild-type) is the most common primary malignant brain tumor in adults and is associated with a severely low survival rate. Treatments offer mere palliation and are ineffective, due, in part, to a lack of understanding of the intricate mechanisms underlying the disease, including the contribution of the tumor microenvironment (TME). Current GBM models continue to face challenges as they lack the critical components and properties required. To address this limitation, we developed innovative and practical three-dimensional (3D) GBM models with structural and mechanical biomimicry and tunability. These models allowed for more accurate emulation of the extracellular matrix (ECM) and vasculature characteristics of the native GBM TME. Additionally, 3D bioprinting was utilized to integrate these complexities, employing a hydrogel composite to mimic the native environment that is known to contribute to tumor cell growth. First, we examined the changes in physical properties that resulted from adjoining hydrogels at diverse concentrations using Fourier-Transform Infrared Spectroscopy (FTIR), compression testing, scanning electron microscopy (SEM), rheological analysis, and degradation analysis. Subsequently, we refined and optimized the embedded bioprinting processes. The resulting 3D GBM models were structurally reliable and reproducible, featuring integrated inner channels and possessing tunable properties to emulate the characteristics of the GBM ECM. Biocompatibility testing was performed via live/dead and AlamarBlue analyses using GBM cells (both commercial cell lines and patient-derived cell lines) encapsulated in the constructs, along with immunohistochemistry staining to understand how ECM properties altered the functions of GBM cells. The observed behavior of GBM cells indicated greater functionality in softer matrices, while the incorporation of hyaluronic acid (HA) into the gelatin methacryloyl (gelMA) matrix enhanced its biomimicry of the native GBM TME. The findings underscore the critical role of TME components, particularly ECM properties, in influencing GBM survival, proliferation, and molecular expression, laying the groundwork for further mechanistic studies. Additionally, the outcomes validate the potential of leveraging 3D bioprinting for GBM modeling, providing a fully controllable environment to explore specific pathways and therapeutic targets that are challenging to study in conventional model systems.
胶质母细胞瘤(GBM,异柠檬酸脱氢酶野生型)是成人中最常见的原发性恶性脑肿瘤,生存率极低。目前的治疗仅能提供姑息治疗,效果不佳,部分原因是对该疾病复杂机制的了解不足,包括肿瘤微环境(TME)的作用。当前的GBM模型仍面临挑战,因为它们缺乏所需的关键组件和特性。为解决这一局限性,我们开发了具有结构和机械仿生及可调性的创新实用三维(3D)GBM模型。这些模型能够更准确地模拟天然GBM TME的细胞外基质(ECM)和脉管系统特征。此外,利用3D生物打印技术整合这些复杂性,采用水凝胶复合材料模拟已知有助于肿瘤细胞生长的天然环境。首先,我们使用傅里叶变换红外光谱(FTIR)、压缩测试、扫描电子显微镜(SEM)、流变学分析和降解分析,研究了不同浓度的相邻水凝胶导致的物理性质变化。随后,我们对嵌入式生物打印工艺进行了优化。最终得到的3D GBM模型在结构上可靠且可重复,具有整合的内部通道,并具有可调特性以模拟GBM ECM的特征。通过使用封装在构建体中的GBM细胞(商业细胞系和患者来源的细胞系)进行活/死分析和AlamarBlue分析以及免疫组织化学染色来进行生物相容性测试,以了解ECM特性如何改变GBM细胞的功能。观察到的GBM细胞行为表明在较软基质中其功能更强,而将透明质酸(HA)掺入甲基丙烯酰化明胶(gelMA)基质中增强了其对天然GBM TME的仿生能力。这些发现强调了TME组件,特别是ECM特性,在影响GBM存活、增殖和分子表达方面的关键作用,为进一步的机制研究奠定了基础。此外,研究结果验证了利用3D生物打印进行GBM建模的潜力,提供了一个完全可控的环境来探索在传统模型系统中难以研究的特定途径和治疗靶点。
