A direct anatomical characterization of the coronary sinus in dogs ( familiaris).

BACKGROUND

The inquiry on the venous drainage of the heart of dogs is still under development, despite its significant importance in the framework of comparative anatomy and its implications for veterinary medicine.

AIM

The objective of the study was to perform a qualitative and biometric characterization of the cardiac veins of dogs.

METHODS

Using the venous bed perfusion technique, semi-synthetic resin (Palatal GP40L 80% and styrene 20% with blue dye) was injected into the venous system of 32 hearts of dogs that died in veterinary clinics, categorized by weight as follows: <10 kg; 10-19 kg; 20-29 kg; ≥30 Kg.

RESULTS

The length and diameter of the coronary sinus for the <10 kg group were 18.49 ± 3.31 and 4.40 ± 0.85 mm. Its morphology was cylindrical in 50% of cases and funnel-shaped in 34.4% of them. Arteriovenous trigone was observed in 93.8% of hearts, with a prevalence of closed configuration in 60% of cases, in both the superior and inferior segments. The diameter of the great cardiac vein at the level of the paraconal interventricular sulcus for the 20-29 kg group was 2.13 ± 0.49 mm, while its distal diameter was 4.03 ± 0.32 mm. The left marginal vein originated mainly in the lower third of the left margin (46.9%), and its caliber at the drainage (2.84 mm) was larger in cases at the level of the coronary sinus than in the great cardiac vein ( = 0.012). Venous anastomoses between the middle and great cardiac veins were observed in 50% of the hearts.

CONCLUSION

The qualitative and biometric characteristics of the venous structures of the heart of dogs were described in detail and categorized by weight groups of the animals. These results are highly useful for the implementation of endovascular devices and the treatment of cardiac diseases.
