供体-受体嵌段共聚物:合成与太阳能电池应用
Donor-Acceptor Block Copolymers: Synthesis and Solar Cell Applications.
作者信息
Nakabayashi Kazuhiro, Mori Hideharu
机构信息
Department of Polymer Science and Engineering, Graduate School of Science and Engineering, Yamagata University, 4-3-16, Jonan, Yonezawa 992-8510, Japan.
出版信息
Materials (Basel). 2014 Apr 22;7(4):3274-3290. doi: 10.3390/ma7043274.
Fullerene derivatives have been widely used for conventional acceptor materials in organic photovoltaics (OPVs) because of their high electron mobility. However, there are also considerable drawbacks for use in OPVs, such as negligible light absorption in the visible-near-IR regions, less compatibility with donor polymeric materials and high cost for synthesis and purification. Therefore, the investigation of non-fullerene acceptor materials that can potentially replace fullerene derivatives in OPVs is increasingly necessary, which gives rise to the possibility of fabricating all-polymer (polymer/polymer) solar cells that can deliver higher performance and that are potentially cheaper than fullerene-based OPVs. Recently, considerable attention has been paid to donor-acceptor (D-A) block copolymers, because of their promising applications as fullerene alternative materials in all-polymer solar cells. However, the synthesis of D-A block copolymers is still a challenge, and therefore, the establishment of an efficient synthetic method is now essential. This review highlights the recent advances in D-A block copolymers synthesis and their applications in all-polymer solar cells.
由于具有高电子迁移率,富勒烯衍生物已被广泛用作有机光伏(OPV)中的传统受体材料。然而,在OPV中使用也存在相当大的缺点,例如在可见光-近红外区域的光吸收可忽略不计、与供体聚合物材料的相容性较差以及合成和纯化成本较高。因此,研究能够在OPV中潜在替代富勒烯衍生物的非富勒烯受体材料变得越来越必要,这使得制造全聚合物(聚合物/聚合物)太阳能电池成为可能,这种电池能够提供更高的性能,并且可能比基于富勒烯的OPV更便宜。最近,供体-受体(D-A)嵌段共聚物受到了相当大的关注,因为它们作为全聚合物太阳能电池中富勒烯替代材料具有广阔的应用前景。然而,D-A嵌段共聚物的合成仍然是一个挑战,因此,建立一种高效的合成方法现在至关重要。本文综述重点介绍了D-A嵌段共聚物合成的最新进展及其在全聚合物太阳能电池中的应用。
