用于穿越血脑屏障的介孔二氧化硅纳米颗粒的尺寸与电荷效应桥接
Bridging Size and Charge Effects of Mesoporous Silica Nanoparticles for Crossing the Blood-Brain Barrier.
作者信息
Chen Yi-Ping, Chou Chih-Ming, Chang Tsu-Yuan, Ting Hao, Dembélé Julien, Chu You-Tai, Liu Tsang-Pai, Changou Chun A, Liu Chien-Wei, Chen Chien-Tsu
机构信息
Graduate Institute of Nanomedicine and Medical Engineering, College of Biomedical Engineering, Taipei Medical University, Taipei, Taiwan.
International PhD Program in Biomedical Engineering, College of Biomedical Engineering, Taipei Medical University, Taipei, Taiwan.
出版信息
Front Chem. 2022 Jun 27;10:931584. doi: 10.3389/fchem.2022.931584. eCollection 2022.
The blood-brain barrier (BBB) is a highly selective cellular barrier that tightly controls the microenvironment of the central nervous system to restrict the passage of substances, which is a primary challenge in delivering therapeutic drugs to treat brain diseases. This study aimed to develop simple surface modifications of mesoporous silica nanoparticles (MSNs) without external stimuli or receptor protein conjugation, which exhibited a critical surface charge and size allowing them to cross the BBB. A series of MSNs with various charges and two different sizes of 50 and 200 nm were synthesized, which showed a uniform mesoporous structure with various surface zeta potentials ranging from +42.3 to -51.6 mV. Confocal microscopic results showed that 50 nm of strongly negatively charged N4-RMSN@PEG/THPMP (∼-40 mV) could be significantly observed outside blood vessels of the brain in (:EGFP) transgenic zebrafish embryos superior to the other negatively charged MSNs. However, very few positively charged MSNs were found in the brain, indicating that negatively charged MSNs could successfully penetrate the BBB. The data were confirmed by high-resolution images of 3D deconvoluted confocal microscopy and two-photon microscopy and zebrafish brain tissue sections. In addition, while increasing the size to 200 nm but maintaining the similar negative charge (∼40 mV), MSNs could not be detected in the brain of zebrafish, suggesting that transport across the BBB based on MSNs occurred in charge- and size-dependent manners. No obvious cytotoxicity was observed in the CTX-TNA2 astrocyte cell line and U87-MG glioma cell line treated with MSNs. After doxorubicin (Dox) loading, N4-RMSN@PEG/THPMP/Dox enabled drug delivery and pH-responsive release. The toxicity assay showed that N4-RMSN@PEG/THPMP could reduce Dox release, resulting in the increase of the survival rate in zebrafish. Flow cytometry demonstrated N4-RMSN@PEG/THPMP had few cellular uptakes. Protein corona analysis revealed three transporter proteins, such as afamin, apolipoprotein E, and basigin, could contribute to BBB penetration, validating the possible mechanism of N4-RMSN@PEG/THPMP crossing the BBB. With this simple approach, MSNs with critical negative charge and size could overcome the BBB-limiting characteristics of therapeutic drug molecules; furthermore, their use may also cause drug sustained-release in the brain, decreasing peripheral toxicity.
血脑屏障(BBB)是一种高度选择性的细胞屏障,它严格控制中枢神经系统的微环境以限制物质的通过,这是递送治疗脑部疾病的治疗药物时面临的主要挑战。本研究旨在开发介孔二氧化硅纳米颗粒(MSNs)的简单表面修饰方法,无需外部刺激或受体蛋白偶联,这些修饰后的MSNs具有关键的表面电荷和尺寸,使其能够穿过血脑屏障。合成了一系列带有不同电荷以及50和200纳米两种不同尺寸的MSNs,它们呈现出具有均匀介孔结构的各种表面zeta电位,范围从 +42.3 到 -51.6 mV。共聚焦显微镜结果表明,在(:EGFP)转基因斑马鱼胚胎的脑外血管中可显著观察到50纳米的强负电荷N4-RMSN@PEG/THPMP(约 -40 mV),优于其他带负电荷的MSNs。然而,在脑中发现的带正电荷的MSNs非常少,这表明带负电荷的MSNs能够成功穿透血脑屏障。3D反卷积共聚焦显微镜和双光子显微镜以及斑马鱼脑组织切片的高分辨率图像证实了这些数据。此外,当尺寸增加到200纳米但保持相似的负电荷(约 -40 mV)时,在斑马鱼脑中未检测到MSNs,这表明基于MSNs穿过血脑屏障的运输以电荷和尺寸依赖的方式发生。在用MSNs处理的CTX-TNA2星形胶质细胞系和U87-MG胶质瘤细胞系中未观察到明显的细胞毒性。负载阿霉素(Dox)后,N4-RMSN@PEG/THPMP/Dox实现了药物递送和pH响应释放。毒性试验表明,N4-RMSN@PEG/THPMP可以减少Dox释放,从而提高斑马鱼的存活率。流式细胞术表明N4-RMSN@PEG/THPMP的细胞摄取很少。蛋白质冠层分析揭示了三种转运蛋白,如afamin、载脂蛋白E和basigin,可能有助于血脑屏障穿透,验证了N4-RMSN@PEG/THPMP穿过血脑屏障的可能机制。通过这种简单的方法,具有关键负电荷和尺寸的MSNs可以克服治疗药物分子的血脑屏障限制特性;此外,它们的使用还可能导致药物在脑中持续释放,降低外周毒性。
