扩张型心肌病患儿不同步性的评估:使用多普勒、组织成像和应变技术对电延迟和机械延迟的比较
Evaluation of dyssynchrony in children with dilated cardiomyopathy: a comparison of electrical and mechanical delay using Doppler, tissue imaging and strain.
作者信息
Rashidi Ghader Fariba, Mahdavi Mohammad, Mehrali Hossein, Dalili Mohammad, Shahzadi Hossein, Abbaszade Reza
机构信息
Department of Pediatric Cardiology, School of Medicine, Rajaie Cardiovascular Research and Medical Institute, Iran University of Medical Sciences, Tehran, Iran.
出版信息
Egypt Heart J. 2025 Apr 16;77(1):37. doi: 10.1186/s43044-025-00633-3.
BACKGROUND
Dilated cardiomyopathy (DCM) is a primary myocardial disease characterized by systolic dysfunction, which can lead to disparity and disorganized contraction, commonly referred to as dyssynchrony. Three types of dyssynchrony include atrioventricular (AVD), interventricular (inter-VD), and intra-LV dyssynchrony (intra-VD). We aimed to investigate the prevalence and interdependence of electrical and mechanical dyssynchrony in order to elucidate the optimizing patients for cardiac resynchronization therapy (CRT).
RESULTS
A total of 37 DCM patients (1-17 years, 51% female) were included in this cross-sectional study. Regarding the intra-VD, inter-VD, and AVD, the study showed inter-VD in 37%, 27%, and 48% by Doppler, Doppler tissue imaging (DTI), and color-coded DTI methods, respectively; however, 70% showed right ventricular free wall delay based on the presence of peak of strain after pulmonic valve closure. 86.5% (32/37) of patients show intra-VD. 100% (8/8) of DCM patients with prolonged QRS (QRSc ≥ 120 ms) had intra-VD, of which 12.5% (1/8) had mild, 25% (2/8) mod, and 62.5% (5/8) severe dyssynchrony. However, 82% (24/29) of patients with narrow QRS (QRSc < 120 ms) also had intra-VD, of which 17% (3/24) were mild, 62.5% (15/24) mod, and 25% (6/24) severe. There were 57% (21/37) of patients with AVD. 77% (10/13) of DCM patients with prolonged PRc (PR ≥ 200 ms) had AVD of which 31% (4/13) of patients had mild, 31% (4/13) mod, and 15% (2/13) severe AVD, while among PRc < 200 ms 46% (11/24) had AVD, of which 37.5% (9/24) had mild AVD, 4% (1/24) mod, and another 4% severe AVD. LVEF was lower and LV GLS, mortality, Pro-BNP, NYHA FC, and severity of intra-VD were higher in the group with QRS ≥ 120 ms, and PR ≥ 200 ms. 27% of patients were expired during the year of study. There was a significant direct correlation between mortality rate, NYHA FC, and pro-BNP with the severity of intra-, inter-VD, and AVD. The most delayed horizontal segments were inferolateral, anterolateral, anterior, and anteroseptal sequentially, while the highest level of vertical dyssynchrony (base to apex) was observed in inferoseptal, inferolateral, and anteroseptal walls in order.
CONCLUSIONS
Our findings indicated that DCM causes both intra- and inter-VD, associated with QRS duration concerning severity, which also results in AVD that are correlated with PRc interval. Notably, a substantial proportion of patients with narrow QRSc also demonstrated intra-VD and inter-VD, while nearly half of those with normal PRc exhibited AVD. Collectively, these observations suggest a lack of complete correspondence between electrical and mechanical dyssynchrony.
背景
扩张型心肌病(DCM)是一种以收缩功能障碍为特征的原发性心肌病,可导致不协调和紊乱的收缩,通常称为不同步。三种不同步类型包括房室(AVD)、室间(inter-VD)和左心室内不同步(intra-VD)。我们旨在研究电不同步和机械不同步的患病率及相互依赖性,以阐明心脏再同步治疗(CRT)的最佳适用患者。
结果
本横断面研究共纳入37例DCM患者(年龄1 - 17岁,51%为女性)。关于intra-VD、inter-VD和AVD,研究显示通过多普勒、组织多普勒成像(DTI)和彩色编码DTI方法检测到的inter-VD分别为37%、27%和48%;然而,基于肺动脉瓣关闭后应变峰值的存在,70%的患者显示右心室游离壁延迟。86.5%(32/37)的患者存在intra-VD。QRS延长(QRSc≥120 ms)的DCM患者中100%(8/8)存在intra-VD,其中12.5%(1/8)为轻度,25%(2/8)为中度,62.5%(5/8)为重度不同步。然而,QRS狭窄(QRSc < 120 ms)的患者中82%(24/29)也存在intra-VD,其中17%(3/24)为轻度,62.5%(15/24)为中度,25%(6/24)为重度。存在AVD的患者占57%(21/37)。PRc延长(PR≥200 ms)的DCM患者中77%(10/13)存在AVD,其中31%(4/13)的患者为轻度,31%(4/13)为中度,15%(2/13)为重度AVD,而PRc < 200 ms的患者中46%(11/24)存在AVD,其中37.5%(9/24)为轻度AVD,4%(1/24)为中度,另有4%为重度AVD。QRSc≥120 ms且PR≥200 ms组的左心室射血分数(LVEF)较低,左心室整体纵向应变(LV GLS)、死亡率、N末端B型利钠肽原(Pro-BNP)、纽约心脏协会功能分级(NYHA FC)和intra-VD严重程度较高。27%的患者在研究年度内死亡。死亡率、NYHA FC和Pro-BNP与intra-VD、inter-VD和AVD的严重程度之间存在显著正相关。最延迟的水平节段依次为下外侧、前外侧、前壁和前间隔,而垂直不同步(心底到心尖)程度最高的依次为下间隔、下外侧和前间隔壁。
结论
我们的研究结果表明,DCM会导致intra-VD和inter-VD,其严重程度与QRS持续时间有关,还会导致与PRc间期相关的AVD。值得注意的是,相当一部分QRSc狭窄的患者也表现出intra-VD和inter-VD,而PRc正常的患者中近一半存在AVD。总体而言,这些观察结果表明电不同步和机械不同步之间缺乏完全对应关系。
