Department for Orthopaedic Trauma, Ulm University, Steínhövelstrasse 9, 89075, Ulm, Germany.
Arch Orthop Trauma Surg. 2011 Mar;131(3):297-302. doi: 10.1007/s00402-010-1145-9. Epub 2010 Jul 6.
Computer-assisted surgery (CAS) can act as an intraoperative ruler in high tibial osteotomy (HTO) to visualize continuously the leg during surgery.
The aim of the study is to evaluate the accuracy of CAS with respect to preoperative planning and postoperative deviation from the planned leg axis in HTO. In addition, the influence of surgeon experience as well as operation time and perioperative complications are analyzed.
A prospective multicenter study case series with follow-up at 6 weeks was performed in six centers. Medial open-wedge HTO with Tomofix(®) was done using computer assisted navigation technique with the Brainlab VV Osteotomy 1.0 module.
Fifty-one patients with medial gonarthritis were treated with navigated HTO. The follow-up rate was 98%. The majority of HTO-CAS patients fell within the tolerated limit of ±3° for leg axis deviation, however, seven patients were reported with deviations outside of this range: three patients had deviations of >3°-4.5° and four patients >4.5°, respectively. Eight intraoperative complications were documented, partially resulting from technical problems associated with the navigation system. During the 6-week follow-up period, three postoperative complications were experienced, all not associated with navigation technology.
In about 85% of cases, a perfect result in terms of deviation of the planned mechanical leg axis could be achieved. Computer assistance in HTO proved to be a helpful tool regarding intraoperative control of leg axis.
Level I, High quality prospective study (all patients were enrolled at the same preoperative planning point with ≥80% follow-up of enrolled patients).
计算机辅助手术(CAS)可作为胫骨高位截骨术(HTO)中的术中标尺,在手术过程中持续可视化腿部。
本研究旨在评估 CAS 在 HTO 中相对于术前计划和术后偏离计划腿部轴线的准确性。此外,还分析了外科医生经验以及手术时间和围手术期并发症的影响。
在六个中心进行了前瞻性多中心病例系列研究,随访时间为 6 周。使用计算机辅助导航技术和 Brainlab VV Osteotomy 1.0 模块进行内侧开放楔形 HTO,Tomofix(®)固定。
51 例内侧膝关节炎患者接受了导航 HTO 治疗。随访率为 98%。大多数 HTO-CAS 患者的腿部轴线偏离在可接受的±3°范围内,但有 7 例报告的偏离超出该范围:3 例患者的偏离度>3°-4.5°,4 例患者的偏离度>4.5°。记录了 8 例术中并发症,部分与导航系统的技术问题有关。在 6 周的随访期间,经历了 3 例术后并发症,均与导航技术无关。
在大约 85%的病例中,可以达到计划机械腿部轴线偏差的完美结果。HTO 中的计算机辅助被证明是一种有助于术中控制腿部轴线的工具。
I 级,高质量前瞻性研究(所有患者均在相同的术前计划点入组,入组患者的随访率≥80%)。
