Yoon Byul Hee, Kim Han Kyu, Park Mun Sun, Kim Seong Min, Chung Seung Young, Lanzino Giuseppe
Department of Neurosurgery, Eulji University Hospital, Daejeon, Korea.
J Korean Neurosurg Soc. 2012 Oct;52(4):391-5. doi: 10.3340/jkns.2012.52.4.391. Epub 2012 Oct 22.
Removal of the anterior clinoid process (ACP) is an essential process in the surgery of giant or complex aneurysms located near the proximal internal carotid artery or the distal basilar artery. An extradural clinoidectomy must be performed within the limits of the meningeal layers surrounding the ACP to prevent morbid complications. To identify the safest method of extradural exposure of the ACP, anatomical studies were done on cadaver heads.
Anatomical dissections for extradural exposure of the ACP were performed on both sides of seven cadavers. Before dividing the frontotemporal dural fold (FTDF), we measured its length from the superomedial apex attached to the periorbita to the posterolateral apex which connects to the anterosuperior end of the cavernous sinus.
The average length of the FTDF on cadaver dissections was 7 mm on the right side and 7.14 mm on the left side. Cranial nerves were usually exposed when cutting FTDF more than 7 mm of the FTDF.
The most delicate area in an extradural anterior clinoidectomy is the junction of the FTDF and the anterior triangular apex of the cavernous sinus. The FTDF must be cut from the anterior side of the triangle at the periorbital side rather than from the dural side. The length of the FTDF incision must not exceed 7 mm to avoid cranial nerve injury.
切除前床突(ACP)是位于颈内动脉近端或基底动脉远端的巨大或复杂动脉瘤手术中的关键步骤。硬膜外前床突切除术必须在围绕ACP的脑膜层范围内进行,以防止出现严重并发症。为了确定硬膜外暴露ACP的最安全方法,对尸体头部进行了解剖学研究。
对7具尸体的双侧进行硬膜外暴露ACP的解剖。在切开额颞硬膜皱襞(FTDF)之前,我们测量了其长度,从附着于眶缘的上内侧顶点到连接海绵窦前上端的后外侧顶点。
尸体解剖中FTDF的平均长度右侧为7mm,左侧为7.14mm。当切开FTDF超过7mm时,通常会暴露颅神经。
硬膜外前床突切除术中最精细的区域是FTDF与海绵窦前三角顶点的交界处。FTDF必须在眶缘侧从三角的前侧而不是从硬膜侧切开。FTDF切口的长度不得超过7mm,以避免损伤颅神经。
