Graduate School of Life and Environmental Sciences, University of Tsukuba, Tsukuba, Ibaraki, Japan.
PLoS One. 2013 Sep 4;8(9):e73925. doi: 10.1371/journal.pone.0073925. eCollection 2013.
Mono-allelic expression at the mouse IGF2/H19 locus is controlled by differential allelic DNA methylation of the imprinting control region (ICR). Because a randomly integrated H19 ICR fragment, when incorporated into the genome of transgenic mice (TgM), was allele-specifically methylated in somatic, but not in germ cells, it was suggested that allele-discriminating epigenetic signature, set within or somewhere outside of the Tg H19 ICR fragment in germ cells, was later translated into a differential DNA methylation pattern. To test if the chicken β-globin HS4 (cHS4) chromatin insulator might interfere with methylation imprinting establishment at the H19 ICR, we inserted the H19 ICR fragment, flanked by a set of floxed cHS4 core sequences, into a human β-globin locus YAC and generated TgM (insulated ICR' TgM). As controls, the cHS4 sequences were removed from one side (5'HS4-deleted ICR') or both sides (pseudo-WT ICR') of the insulated ICR' by in vivo cre-loxP recombination. The data show that while maternally inherited transgenic H19 ICR was not methylated in insulated ICR' TgM, it was significantly methylated upon paternal transmission, though the level was lower than in the pseudo-WT ICR' control. Because this reduced level of methylation was also observed in the 5'HS4-deleted ICR' TgM, we speculate that the phenotype is due to VEZF1-dependent demethylation activity, rather than the insulator function, borne in cHS4. Collectively, although we cannot rule out the possibility that cHS4 is incapable of blocking an allele-discriminating signal from outside of the transgene, the epigenetic signature appears to be marked intrinsically within the H19 ICR.
在小鼠 IGF2/H19 基因座上的单等位基因表达受印迹控制区(ICR)的差异等位基因 DNA 甲基化控制。由于随机整合的 H19 ICR 片段在转基因小鼠(TgM)的基因组中,在体细胞中特异性甲基化,但在生殖细胞中不甲基化,因此有人提出,在生殖细胞中,在 Tg H19 ICR 片段内或其外部的某个位置,存在一种区分等位基因的表观遗传特征,该特征随后被转化为一种差异 DNA 甲基化模式。为了测试鸡β-球蛋白 HS4(cHS4)染色质绝缘子是否会干扰 H19 ICR 的甲基化印迹建立,我们将 H19 ICR 片段插入一组被 floxed cHS4 核心序列包围的人β-球蛋白基因座 YAC 中,并生成 TgM(绝缘 ICR' TgM)。作为对照,通过体内 Cre-loxP 重组从绝缘 ICR'的一侧(5'HS4 缺失 ICR')或两侧(假 WT ICR')去除 cHS4 序列。数据表明,虽然母系遗传的转基因 H19 ICR 在绝缘 ICR' TgM 中未被甲基化,但在父系传递时,它显著被甲基化,尽管水平低于假 WT ICR'对照。由于在 5'HS4 缺失 ICR' TgM 中也观察到这种降低的甲基化水平,我们推测这种表型是由于 VEZF1 依赖性去甲基化活性,而不是 cHS4 承载的绝缘子功能引起的。总的来说,尽管我们不能排除 cHS4 不能阻断来自转基因外部的等位基因区分信号的可能性,但表观遗传特征似乎内在地标记在 H19 ICR 中。
