Laboratory of Biological Structure Mechanics, IRCCS Galeazzi Orthopaedic Institute, Milan, Italy ; Department of Internal Medicine II-Cardiology, Ulm University, Ulm, Germany.
PLoS One. 2013 Oct 11;8(10):e76697. doi: 10.1371/journal.pone.0076697. eCollection 2013.
A post contrast magnetic resonance imaging study has been performed in a wide population of low back pain patients to investigate which radiological and phenotypic characteristics influence the penetration of the contrast agent in lumbar discs in vivo. 37 patients affected by different pathologies (disc herniation, spondylolisthesis, foraminal stenosis, central canal stenosis) were enrolled in the study. The selected population included 26 male and 11 female subjects, with a mean age of 42.4 ± 9.3 years (range 18-60). Magnetic resonance images of the lumbar spine were obtained with a 1.5 T scanner (Avanto, Siemens, Erlangen, Germany) with a phased-array back coil. A paramagnetic non-ionic contrast agent was injected with a dose of 0.4 ml/kg. T1-weighted magnetic resonance images were subsequently acquired at 5 time points, 5 and 10 minutes, 2, 4 and 6 hours after injection. Endplates presented clear enhancement already 5 minutes after injection, and showed an increase in the next 2 hours followed by a decrease. At 5 and 10 minutes, virtually no contrast medium was present inside the intervertebral disc; afterwards, enhancement significantly increased. Highly degenerated discs showed higher enhancement in comparison with low and medium degenerated discs. Discs classified as Pfirrmann 5 showed a statistically significant higher enhancement than Pfirrmann 1, 2 and 3 at all time points but the first one, possibly due to vascularization. Disc height collapse and Modic changes significantly increased enhancement. Presence of endplate defects did not show any significant influence on post contrast enhancement, but the lack of a clear classification of endplate defects as seen on magnetic resonance scans may be shadowing some effects. In conclusion, disc height, high level of degeneration and presence of Modic changes are factors which increase post contrast enhancement in the intervertebral disc. The effect of age could not be demonstrated.
一项针对广泛的腰痛患者群体进行的对比增强磁共振成像研究旨在调查哪些影像学和表型特征会影响腰椎间盘内对比剂的渗透。该研究纳入了 37 名患有不同疾病(椎间盘突出症、脊椎滑脱、椎间孔狭窄、椎管狭窄)的患者。该研究群体包括 26 名男性和 11 名女性,平均年龄为 42.4 ± 9.3 岁(范围 18-60 岁)。使用 1.5T 扫描仪(西门子,德国埃朗根)和相控阵背线圈获取腰椎磁共振图像。使用 0.4ml/kg 的剂量注射顺磁性非离子型对比剂。注射后 5 个时间点(5 分钟和 10 分钟、2 小时、4 小时和 6 小时)获取 T1 加权磁共振图像。注入后 5 分钟内,终板就出现了明显的增强,在接下来的 2 小时内增强程度增加,然后再减弱。在 5 分钟和 10 分钟时,椎间盘内几乎没有对比剂;之后,增强效果显著增加。与低退变和中退变的椎间盘相比,高度退变的椎间盘显示出更高的增强程度。在所有时间点,Pfirrmann 5 级椎间盘的增强程度明显高于 Pfirrmann 1、2 和 3 级,而与 Pfirrmann 1 级相比,差异具有统计学意义,这可能与血管化有关。椎间盘高度塌陷和 Modic 改变显著增加了增强程度。终板缺损的存在对对比增强没有显示出任何显著影响,但磁共振扫描所见的终板缺损缺乏明确分类可能掩盖了一些影响。总之,椎间盘高度、高度退变和 Modic 改变是增加椎间盘对比增强的因素。年龄的影响无法证明。
