Bigras Gilbert, Dong Wei-Feng, Canil Sarah, Hugh Judith, Berendt Richard, Wood George, Yang Hua
*Department of Laboratory Medicine and Pathology, Cross Cancer Institute †Department of Laboratory Medicine and Pathology, University of Alberta, Edmonton ‡Department of Laboratory Medicine and Pathology, University of Calgary, Calgary, AB, Canada.
Appl Immunohistochem Mol Morphol. 2017 Nov/Dec;25(10):687-695. doi: 10.1097/PAI.0000000000000371.
There is a pressing need for an objective decision tool to guide therapy for breast cancer patients that are estrogen receptor positive and HER2/neu negative. This subset of patients contains a mixture of luminal A and B tumors with good and bad outcomes, respectively. The 2 main current tools are on the basis of immunohistochemistry (IHC) or gene expression, both of which rely on the expression of distinct molecular groups that reflect hormone receptors, HER2/neu status, and most importantly, proliferation. Despite the success of a proprietary molecular test, definitive superiority of any method has not yet been demonstrated. Ki67 IHC scoring assessments have been shown to be poorly reproducible, whereas molecular testing is costly with a longer turnaround time. This work proposes an objective Ki67 index using image analysis that addresses the existing methodological issues of Ki67 quantitation using IHC on paraffin-embedded tissue. Intrinsic bias related to numerical assessment performed on IHC is discussed as well as the sampling issue related to the "peel effect" of tiny objects within a thin section. A new nonbiased stereological parameter (VV) based on the Cavalieri method is suggested for use on a double-stained Ki67/cytokeratin IHC slide. The assessment is performed with open-source ImageJ software with interobserver concordance between 3 pathologists being high at 93.5%. Furthermore, VV was found to be a superior method to predict an outcome in a small subset of breast cancer patients when compared with other image analysis methods being used to determine the Ki67 labeling index. Calibration methodology is also discussed to further this IHC approach.
迫切需要一种客观的决策工具,以指导雌激素受体阳性且HER2/neu阴性的乳腺癌患者的治疗。这类患者包含管腔A型和B型肿瘤,其预后分别有好有坏。当前的两种主要工具基于免疫组织化学(IHC)或基因表达,二者均依赖于反映激素受体、HER2/neu状态,以及最重要的增殖情况的不同分子组的表达。尽管一种专利分子检测取得了成功,但尚未证明任何方法具有绝对优势。已证明Ki67免疫组化评分评估的可重复性较差,而分子检测成本高昂且周转时间较长。这项工作提出了一种使用图像分析的客观Ki67指数,解决了在石蜡包埋组织上使用免疫组化进行Ki67定量时存在的现有方法学问题。讨论了与免疫组化数值评估相关的内在偏差,以及与薄切片内微小物体的“剥离效应”相关的采样问题。建议在双染的Ki67/细胞角蛋白免疫组化玻片上使用基于卡瓦列里方法的新的无偏体视学参数(VV)。使用开源ImageJ软件进行评估,3名病理学家之间的观察者间一致性高达93.5%。此外,与用于确定Ki67标记指数的其他图像分析方法相比,发现VV是预测一小部分乳腺癌患者预后的更优方法。还讨论了校准方法,以进一步完善这种免疫组化方法。
