Sheng Han-Song, Shen Fang, Lin Jian, Bai Guang-Hui, Lin Fen-Chun, Li Dan-Dong, Zhang Nu
Department of Neurosurgery, Second Affiliated Hospital of Wenzhou Medical University, Wenzhou Department of Neurosurgery, Ningbo No. 2 Hospital, Ningbo Department of Radiology, Second Affiliated Hospital of Wenzhou Medical University, Wenzhou, China.
Medicine (Baltimore). 2017 Jun;96(22):e7055. doi: 10.1097/MD.0000000000007055.
The superior sagittal sinus (SSS) is the major dural sinuses that receive a considerable amount of venous drainage. Interruption of its posterior third has been suggested to cause intracranial hypertension and lead to potentially fatal consequences.
We presented a 22-year-old man with a severe headache and scalp bleeding after a head chop wound. Physical examination identified a 20-cm straight laceration in his parietooccipital scalp. Computed tomography (CT) demonstrated a depressed cranial fracture (DCF) in the left parietooccipital bone, a fracture line across the midline to the right side, and penetrations of bone fragments into the brain parenchyma.
Traumatic open DCF in left parietooccipital bone.
An emergent left parietooccipital craniotomy, followed by cranioplasty to restore the depressed bone flap, was delivered to the patient. Postoperative CT confirmed successful elevation of the DCF and removal of intracerebral bone fragments. However, postoperative CT angiography (CTA) demonstrated an absence of venous flow distal to the fracture, suggesting occlusion of the posterior third of SSS. MRV revealed a persistent absence of venous flow in the posterior third of SSS with dilated cortical venous drainage. Anticoagulation treatment was initiated 3 days after surgery, and follow-up CTA and digital subtraction angiography showed gradually improved patency in the anterior and middle two-thirds of SSS.
Despite occlusion of the posterior third of SSS, patient's symptoms resolved after the operation and he was discharged without complications.
The favorable clinical outcome after complete occlusion of the posterior third of the SSS has rarely been reported and it might be explained by our timely surgical intervention and development of compensatory cerebral collateral circulation.
上矢状窦(SSS)是主要的硬脑膜窦,接收大量静脉引流。有人提出中断其后三分之一会导致颅内高压并引发潜在的致命后果。
我们收治了一名22岁男性,他在头部砍伤后出现严重头痛和头皮出血。体格检查发现其顶枕部头皮有一条20厘米的直线状裂伤。计算机断层扫描(CT)显示左侧顶枕骨有凹陷性颅骨骨折(DCF),骨折线穿过中线至右侧,并有骨碎片刺入脑实质。
左侧顶枕骨创伤性开放性DCF。
对患者进行了紧急左侧顶枕开颅手术,随后进行颅骨成形术以恢复凹陷的骨瓣。术后CT证实DCF成功复位且脑内骨碎片已清除。然而,术后CT血管造影(CTA)显示骨折远端无静脉血流,提示SSS后三分之一闭塞。磁共振静脉血管造影(MRV)显示SSS后三分之一持续无静脉血流,皮质静脉引流扩张。术后3天开始抗凝治疗,随访CTA和数字减影血管造影显示SSS前三分之二和中间三分之一的通畅情况逐渐改善。
尽管SSS后三分之一闭塞,但患者术后症状缓解,出院时无并发症。
SSS后三分之一完全闭塞后出现良好临床结果的情况鲜有报道,这可能是由于我们及时的手术干预以及代偿性脑侧支循环的形成。
