Simplified Dynamic Phantom for Pediatric Renography: A Description of Instrument and its Performance.

OBJECTIVES

Renography is used for the diagnostic evaluation of pediatric patients with a suspected obstruction of urinary tract or impaired renal function. The recommended dose for children have been released by the European Association of Nuclear Medicine, Society of Nuclear Medicine and Molecular Imaging, and Japanese Society of Nuclear Medicine. Since acquisition counts in dynamic scintigraphy are affected by the administered doses and sensitivity of the scintillation camera, the scan procedure should be determined independently. In this study, we constructed simplified dynamic phantom imitating pediatric renography and tested its performance.

METHODS

Simplified dynamic phantom consisted of three components (i.e., infusion, imitated kidney, and drainage sections). The infusion rates (mL/min) were determined by comparing the time activity curves obtained from patients with normal renal function. The time-points of the maximum counts (T), as well as the two-thirds and one-half of the maximum counts (T and T) were measured in different doses using the phantom with the best-match infusion rate and duration, and low-energy general-purpose (LEGP) or low-energy high-resolution (LEHR) collimators and applying different attenuations.

RESULTS

The best-match infusion rates of the phantom to imitate the time activity curve of the normal renal function were 42.0, 1.0, 0.6, and 0.3 mL/min in the arterial, secretory, early-excretory, and late-excretory phases, respectively. When 30 MBq, LEHR collimator and non-water-equivalent phantom were applied, T, T, and T were 242±15.3, 220±10.0 and 317±25.2 seconds, respectively. Using LEGP collimator and (3 MBq of activity) 5-cm water-equivalent phantom, T, T, and T values were estimated as 242±5.8, 213±11.5, and 310±17.3 sec, respectively.

CONCLUSION

Our simplified dynamic phantom for pediatric renography could imitate the time activity curves obtained from patients with normal renal function. T, T, and T could be measured under various settings of dose, collimator, and tissue attenuation.
