Kim Sung-Jae, Kim Sung-Hwan, Han Hee-Don, Lee In-Sung, Kim Sung-Guk, Chun Yong-Min
Department of Orthopaedic Surgery, Arthroscopy and Joint Research Institute, Yonsei University Health System, CPO Box 8044, 134, Shinchon-dong, Seodaemun-gu, Seoul 120-752, South Korea. E-mail address for S.-J. Kim:
JBJS Essent Surg Tech. 2012 Apr 11;2(2):e8. doi: 10.2106/JBJS.ST.K.00038. eCollection 2012 Apr.
We present surgical techniques for the anatomical reconstruction of the popliteus tendon and the lateral collateral ligament (LCL) with use of a tibialis posterior allograft for posterolateral corner insufficiency combined with anterolateral transtibial single-bundle posterior cruciate ligament (PCL) reconstruction with use of an Achilles tendon-bone allograft with a one-incision technique.
STEP 1 CREATE THE PORTALS: Use a parapatellar high anteromedial portal, a far anterolateral portal, and a high posteromedial portal.
STEP 2 PREPARE THE TIBIAL TUNNEL AND FEMORAL SOCKET FOR THE PCL RECONSTRUCTION: To reduce the graft/socket divergence, (1) flex the knee >100°, (2) push the proximal part of the tibia backward as much as possible, and (3) introduce the cannulated headed reamer through the far anterolateral portal with a smooth plastic sheath and push up posteriorly to make contact with the lateral femoral condyle.
STEP 3 PREPARE PASS AND FIX THE GRAFT FOR THE PCL RECONSTRUCTION: Tie a 9-mm EndoPearl device securely to the tip of the tendon to improve the fixation strength.
STEP 4 MAKE THE SKIN INCISION AND DEVELOP THE SURGICAL PLANE FOR THE POSTEROLATERAL CORNER RECONSTRUCTION: Create a 7-mm fibular tunnel in a counterclockwise direction to avoid breaking the lateral cortex of the fibular tunnel or injuring the peroneal nerve.
STEP 5 PREPARE PASS AND FIX THE GRAFT FOR THE POSTEROLATERAL CORNER RECONSTRUCTION: Change the patient's position to a lateral or semi-lateral decubitus position to prevent an inappropriate posterolateral corner reconstruction by the posterolateral corner of the knee sagging in the supine position due to gravity.
STEP 6 POSTOPERATIVE REHABILITATION: Immobilize the knee in extension, with the proximal part of the tibia supported with cotton pads to prevent posterior drooping, which may lead to graft stretch or failure.
We performed a two-year follow-up study comparing the procedures described here (Group A) with the same PCL reconstruction technique combined with a modified biceps rerouting tenodesis to address the posterolateral corner deficiency (Group B).
IndicationsContraindicationsPitfalls & Challenges.
我们介绍了用于腘肌腱和外侧副韧带(LCL)解剖重建的手术技术,采用胫后肌腱同种异体移植物治疗后外侧角功能不全,并采用单切口技术,使用跟腱-骨同种异体移植物进行前外侧经胫骨单束后交叉韧带(PCL)重建。
步骤1 创建入口:使用髌旁高位前内侧入口、远侧前外侧入口和高位后内侧入口。
步骤2 为PCL重建准备胫骨隧道和股骨骨道:为减少移植物/骨道的偏差,(1)将膝关节屈曲>100°,(2)尽可能将胫骨近端向后推,(3)通过带有光滑塑料鞘的远侧前外侧入口插入空心头铰刀,并向后推使其与股骨外侧髁接触。
步骤3 准备、穿入并固定PCL重建的移植物:将一个9毫米的EndoPearl装置牢固地系在肌腱末端,以提高固定强度。
步骤4 做皮肤切口并为后外侧角重建开辟手术平面:沿逆时针方向创建一个7毫米的腓骨隧道,以避免破坏腓骨隧道的外侧皮质或损伤腓总神经。
步骤5 准备、穿入并固定后外侧角重建的移植物:将患者体位改为侧卧位或半侧卧位,以防止因重力作用,仰卧位时膝关节后外侧角下垂导致后外侧角重建不当。
步骤6 术后康复:将膝关节伸直位固定,胫骨近端用棉垫支撑,以防止向后下垂,这可能导致移植物拉伸或失效。
我们进行了一项为期两年的随访研究,将此处描述的手术方法(A组)与相同的PCL重建技术联合改良的肱二头肌转位腱固定术治疗后外侧角缺损的方法(B组)进行比较。
适应证、禁忌证、陷阱与挑战。
