Zhang Weimin, Liu Yuqing, Zhang Lipeng, Chen Jun
School of Chemistry and Chemical Engineering, Shandong University of Technology, Zibo 255049, China.
ARC Centre of Excellence for Electromaterials Science, Intelligent Polymer Research Institute, Australian Institute of Innovative Materials, Innovation Campus, University of Wollongong, Wollongong, NSW 2522, Australia.
Nanomaterials (Basel). 2019 Oct 2;9(10):1402. doi: 10.3390/nano9101402.
Recently, zinc-air batteries (ZABs) have been receiving attention due to their theoretically high energy density, excellent safety, and the abundance of zinc resources. Typically, the performance of the zinc air batteries is determined by two catalytic reactions on the cathode-the oxygen reduction reaction (ORR) and the oxygen evolution reaction (OER). Therefore, intensive effort has been devoted to explore high performance electrocatalysts with desired morphology, size, and composition. Among them, single-atom catalysts (SACs) have emerged as attractive and unique systems because of their high electrocatalytic activity, good durability, and 100% active atom utilization. In this review, we mainly focus on the advance application of SACs in zinc air batteries in recent years. Firstly, SACs are briefly compared with catalysts in other scales (i.e., micro- and nano-materials). A main emphasis is then focused on synthesis and electrocatalytic activity as well as the underlying mechanisms for mono- and dual-metal-based SACs in zinc air batteries catalysis. Finally, a prospect is provided that is expected to guide the rational design and synthesis of SACs for zinc air batteries.
近年来,锌空气电池(ZABs)因其理论上的高能量密度、出色的安全性以及丰富的锌资源而备受关注。通常,锌空气电池的性能由阴极上的两个催化反应——氧还原反应(ORR)和析氧反应(OER)决定。因此,人们致力于探索具有理想形态、尺寸和组成的高性能电催化剂。其中,单原子催化剂(SACs)因其高电催化活性、良好的耐久性和100%的活性原子利用率而成为有吸引力且独特的体系。在这篇综述中,我们主要关注近年来单原子催化剂在锌空气电池中的应用进展。首先,将单原子催化剂与其他尺度的催化剂(即微纳材料)进行简要比较。然后重点关注单金属和双金属基单原子催化剂在锌空气电池催化中的合成、电催化活性及其潜在机制。最后,给出了一个展望,有望指导锌空气电池单原子催化剂的合理设计与合成。
