Zhang Miao, Li Xifei, Wang Xiaohua, Li Dejun, Zhao Naiqin
Tianjin International Joint Research Centre of Surface Technology for Energy Storage Materials, School of Physics and Materials Science, Tianjin Normal University, Tianjin, China.
School of Materials Science and Engineering and Tianjin Key Laboratory of Composite and Functional Materials, Tianjin University, Tianjin, China.
Front Chem. 2020 Jan 8;7:887. doi: 10.3389/fchem.2019.00887. eCollection 2019.
A convenient and scalable hydrothermal method was developed for the fabrication of the core-branch FeO@NiO nanorods arrays directly grown on flexible carbon cloth (denoted as FeO@NiO/CC). Such a unique architecture was applied as an electrode of the supercapacitors. As a result, the FeO@NiO/CC exhibited a high areal capacitance ~800 mF cm at 10 mA cm, which was about 10 times increase with respect to FeO nanorods array grown on carbon cloth (FeO/CC). The FeO@NiO/CC also had the long life cycle (96.8 % capacitance retention after 16,000 cycles) and remarkable rate capability (44.0 % capacitance loss at a very large current density of 100 mA cm). The superior performance of the FeO@NiO/CC should be ascribed to the reduction of the contact resistance and the free-standing structure of the flexible electrode. This study provides a novel strategy to construct high-performance flexible electrode materials with unique core-branch structure by incorporating two different pseudocapacitive materials.
开发了一种便捷且可扩展的水热法,用于制备直接生长在柔性碳布上的核-支状FeO@NiO纳米棒阵列(记为FeO@NiO/CC)。这种独特的结构被用作超级电容器的电极。结果表明,FeO@NiO/CC在10 mA cm时表现出高达~800 mF cm的面积电容,相对于生长在碳布上的FeO纳米棒阵列(FeO/CC)增加了约10倍。FeO@NiO/CC还具有长寿命周期(16000次循环后电容保持率为96.8%)和显著的倍率性能(在100 mA cm的非常大的电流密度下电容损失44.0%)。FeO@NiO/CC的优异性能应归因于接触电阻的降低和柔性电极的独立结构。本研究通过结合两种不同的赝电容材料,提供了一种构建具有独特核-支状结构的高性能柔性电极材料的新策略。
