Microfluidic-based processors and circuits design.

Droplets produced within microfluidics have not only attracted the attention of researchers to develop complex biological, industrial and clinical testing systems but also played a role as a bit of data. The flow of droplets within a network of microfluidic channels by stimulation of their movements, trajectories, and interaction timing, can provide an opportunity for preparation of complex and logical microfluidic circuits. Such mechanical-based circuits open up avenues to mimic the logic of electrical circuits within microfluidics. Recently, simple microfluidic-based logical elements such as AND, OR, and NOT gates have been experimentally developed and tested to model basic logic conditions in laboratory settings. In this work, we develop new microfluidic networks, control the shape of channels and speed of droplet movement, and regulate the size of bubbles in order to extend the logical elements to six new logic gates, including AND/OR type 1, AND/OR type 2, NOT type 1, NOT type 2, Flip-Flop, Synchronizer, and a parametric model of T-junction as a bubble generator. We further designed and simulated a novel microfluidic Decoder 1 to 2, a Decoder 2 to 4, and a microfluidic circuit that combines several individual logic gates into one complex circuit. Further fabrication and experimental testing of these newly introduced logic gates within microfluidics enable implementing complex circuits in high-throughput microfluidic platforms for tissue engineering, drug testing and development, and chemical synthesis and process design.
