Tan Tong Ling, Krusnamurthy Poovarasi A/P, Nakajima Hideki, Rashid Suraya Abdul
Institute of Advanced Technology, Universiti Putra Malaysia 43400 UPM Serdang Selangor Malaysia
Department of Chemical and Environmental Engineering, Faculty of Engineering, Universiti Putra Malaysia 43400 UPM Serdang Selangor Malaysia.
RSC Adv. 2020 May 18;10(32):18740-18752. doi: 10.1039/d0ra01268h. eCollection 2020 May 14.
Fluoride contamination has been recognised as one of the major problems worldwide, imposing a serious threat to human health and affecting the safety of drinking water. Adsorption is one of the widely considered appropriate technologies for water defluorination. The present study describes the preparation of a zirconium-based metal organic framework (MOF-801) adsorbent using a solvothermal method and its adsorption efficiency for removal of fluoride ions from water. The morphology of MOF-801 was characterized by PXRD, FESEM and XPS, and the pore structure and surface area were calculated according to BET. It was found that the synthesized MOF-801 showed the distinguishable octahedral shape particle with a lattice spacing of 0.304 nm, indicative of (011) planes of ZrO. Adsorption studies were carried out to study the defluorination effectiveness by varying contact time (30-150 min), adsorbent dose (0.3-1.5 g L), adsorbate concentration (5-25 mg L), as well as kinetics and isotherms. The maximum removal efficiency for fluoride using MOF-801 at equilibrium was found to be 92.3%. Moreover, the adsorption kinetic studies indicate that the overall fluoride adsorption process was best described by pseudo-second-order kinetics. The adsorption data were well-fitted with the Langmuir isotherm model ( = 0.9925) with maximum adsorption capacity of 19.42 mg g. The synthesized MOF-801 had good reusability and was used in up to four cycles for fluoride removal attaining around 79% removal efficiency after the fourth cycle. All the results suggested that the synthesized MOF-801 has potential to be an excellent adsorbent for wastewater defluorination treatment.
氟污染已被公认为全球主要问题之一,对人类健康构成严重威胁,并影响饮用水安全。吸附是一种被广泛认为适用于水脱氟的技术。本研究描述了采用溶剂热法制备锆基金属有机框架(MOF-801)吸附剂及其从水中去除氟离子的吸附效率。通过PXRD、FESEM和XPS对MOF-801的形态进行了表征,并根据BET计算了其孔结构和表面积。结果发现,合成的MOF-801呈现出可区分的八面体形状颗粒,晶格间距为0.304 nm,表明为ZrO的(011)平面。通过改变接触时间(30 - 150分钟)、吸附剂剂量(0.3 - 1.5 g/L)、吸附质浓度(5 - 25 mg/L)以及动力学和等温线来进行吸附研究,以考察脱氟效果。发现在平衡状态下,使用MOF-801对氟的最大去除效率为92.3%。此外,吸附动力学研究表明,整体氟吸附过程用伪二级动力学能得到最佳描述。吸附数据与Langmuir等温线模型拟合良好( = 0.9925),最大吸附容量为19.42 mg/g。合成的MOF-801具有良好的可重复使用性,可用于多达四个循环的氟去除,第四个循环后去除效率达到约79%。所有结果表明,合成的MOF-801有潜力成为废水脱氟处理的优良吸附剂。
