Jiang Ke, Wu Wei, Ren Boyong, Li Meng, He Jiaxing, Xu Enze, Liu Junwu, Tong Guoqing, Zhong Honghai, Jiang Yang
School of Materials Science and Engineering, Hefei University of Technology Hefei 230009 China
RSC Adv. 2022 May 11;12(22):14175-14182. doi: 10.1039/d2ra01012g. eCollection 2022 May 5.
Highly crystalline glass-ceramics were successfully manufactured a one-step direct cooling method using Shuangqishan (Fujian, China) gold tailings as raw materials. A series of glass-ceramics were prepared by controlling the gold tailings addition and post-treatment. X-ray diffraction results show that the crystalline phase of glass-ceramics samples with high tailing addition content (65-80 wt%) is akermanite phase (CaMgSiO). By contrast, the main phase of 60 wt% and 55 wt% tailings addition samples is diopside (CaMgSiO) crystalline phase. In addition, although glass-ceramics have typical fracture characteristics of brittle materials, the crack propagation in the fracture process is disturbed by grains, resulting in the deviation of the fracture path in terms of macroscopic and microcosmic observation. Based on the investigation of samples with different tailings additions, glass-ceramics with 60 wt% tailings contents show excellent mechanical properties with a density of 2.89 g cm, a Vickers hardness value of 8.17 GPa, and a flexural strength of 116 MPa after 950 °C heat treatment. This study further confirms the possibility of using Shuangqi Mountain gold tailings as the raw materials for highly crystalline glass-ceramics, which shows great potential for application in mass production.
采用一步直接冷却法,以双旗山(中国福建)金矿尾矿为原料,成功制备出了高结晶度的微晶玻璃。通过控制金矿尾矿添加量和后处理工艺,制备了一系列微晶玻璃。X射线衍射结果表明,尾矿添加量高(65 - 80 wt%)的微晶玻璃样品的晶相为钙镁黄长石相(CaMgSiO)。相比之下,尾矿添加量为60 wt%和55 wt%的样品的主相为透辉石(CaMgSiO)晶相。此外,尽管微晶玻璃具有典型的脆性材料断裂特征,但在断裂过程中裂纹扩展受到晶粒的干扰,导致从宏观和微观观察来看断裂路径发生偏差。基于对不同尾矿添加量样品的研究,尾矿含量为60 wt%的微晶玻璃在950℃热处理后表现出优异的力学性能,密度为2.89 g/cm,维氏硬度值为8.17 GPa,抗弯强度为116 MPa。本研究进一步证实了利用双旗山金矿尾矿作为高结晶度微晶玻璃原料的可能性,这显示出其在大规模生产中的巨大应用潜力。
