Modeling Evolution of Cutting Force in Ultrasonically Assisted Drilling of Carbon Fiber Reinforced Plastics.

In this study, the effects of process parameters (feed rate, spindle speed, and ultrasonic power level) on the cutting force and delamination in the ultrasonic vibration-assisted drilling of carbon fiber-reinforced plastics (CFRPs) have been investigated. A series of drilling tests under various conditions defined by the design of experiment technique were conducted. The evolution of the cutting force during drilling cycles was measured and analyzed. Experimental analysis results based on the Taguchi method and analysis of variance show that the spindle speed is an influential factor affecting the cutting force with a contribution of 75.36%, and the feed rate significantly affects the delamination damage with a contribution of 46.57%. In addition, the cutting force was found to increase with drilling cycles at different rates, which depends on the process parameters used in drilling. The evolution behavior of cutting force was well fitted based on the process parameters by proposed regression models. Experimental validation indicates that the predicted forces show reasonable agreement with measured values under different conditions and reveal good prediction performances, with a root mean square error of 5.6 and a mean absolute percentage error of 5.8%. In drilling tests with variable cutting conditions, the evolution of the cutting forces predicted based on the selected parameters was successfully verified when compared with the measured results, with RMSE and MAPE values of 7.55 and 5.61%, respectively. As a conclusion, this predictive model provides an effective basis for selecting appropriate drilling parameters to suppress the cutting force on CFRP composites.
