Qiu Siyao, Wang Wei, Lu Jibao, Sun Rong
Shenzhen Institute of Advanced Electronic Materials, Shenzhen Institute of Advanced Technology, Chinese Academy of Sciences Shenzhen 518055 China
Shenzhen Institute of Advanced Technology, Chinese Academy of Sciences Shenzhen 518055 China.
RSC Adv. 2022 Jul 1;12(30):19240-19245. doi: 10.1039/d2ra03449b. eCollection 2022 Jun 29.
The anion exchange membrane (AEM) is a main component for AEM fuel cells. Recently, a series of electrolytes based on covalent organic frameworks (COFs) functionalized with quaternary ammonium (QA) of showed extraordinary ionic conductivities thanks to the intrinsic porosity of the COF structures, which also provide a robust backbone for good mechanical strength. However, the chemical stability of the COF-based AEMs in alkaline conditions is yet to be understood. Here we systematically investigate the chemical degradation of the COF-based structures tethered with alkyl spacers by combining molecular dynamics (MD) simulations and density functional theory (DFT) calculations. We find that the water environment protects the cationic groups from chemical degradation in terms of both physical and chemical effects, which play a synergistic role. Moreover, we introduce the effective density of water as an order parameter to quantitatively characterize the level of degradation of the COF-based systems with similar design of architecture. The results provide guidance for estimation of the chemical stability of COF-based AEMs.
阴离子交换膜(AEM)是AEM燃料电池的主要组件。最近,一系列基于用季铵(QA)功能化的共价有机框架(COF)的电解质,由于COF结构的固有孔隙率而表现出非凡的离子电导率,这也为良好的机械强度提供了坚固的骨架。然而,基于COF的AEM在碱性条件下的化学稳定性尚不清楚。在这里,我们通过结合分子动力学(MD)模拟和密度泛函理论(DFT)计算,系统地研究了与烷基间隔基相连的基于COF的结构的化学降解。我们发现,水环境在物理和化学效应方面都保护阳离子基团免受化学降解,这两种效应起到协同作用。此外,我们引入水的有效密度作为一个序参量,以定量表征具有相似结构设计的基于COF的体系的降解程度。这些结果为评估基于COF的AEM的化学稳定性提供了指导。
