Heart Rate Variability Control Using a Biofeedback and Wearable System.

Heart rate variability is an important physiological parameter in medicine. This parameter is used as an indicator of physiological and psychological well-being and even of certain pathologies. Research on biofeedback integrates the fields of biological application (physiological behavior), system modeling, and automated control. This study proposes a new method for modeling and controlling heart rate variability as heart rate acceleration, a model expressed in the frequency domain. The model is obtained from excitation and response signals from heart rate variability, which through the instrumental variables method and the minimization of a cost function delivers a transfer function that represents the physiological phenomenon. This study also proposes the design of an adaptive controller using the reference model. The controller controls heart rate variability based on the light actuators designed here, generating a conditioned reflex that allows individuals to self-regulate their state through biofeedback, synchronizing this action to homeostasis. Modeling is conducted in a target population of middle-aged men who work as firefighters and forest firefighters. This study validates the proposed model, as well as the design of the controllers and actuators, through a simple experiment based on indoor cycling. This experiment has different segments, namely leaving inertia, non-controlled segment, and actively controlled segment.
