一种有助于在四边形表面骨折中以适当角度拧入的装置:105 度钻头附件。

A device that facilitates screwing at an appropriate angle in quadrilateral surface fractures: 105-degree drill attachment.

机构信息

Department of Orthopedics and Traumatology, Faculty of Medicine, Muğla Sıtkı Koçman University, Muğla, Turkey.

Department of Orthopedics and Traumatology, Faculty of Medicine, Balıkesir University, Balıkesir, Turkey.

出版信息

Turk J Med Sci. 2022 Jun;52(3):816-824. doi: 10.55730/1300-0144.5378. Epub 2022 Jun 16.

Abstract

BACKGROUND

Within this study, we aimed to investigate the radiological and functional outcomes of acetabular fractures involving quadrilateral surface using 105° drill attachment in the anterior intrapelvic approach.

METHODS

The 35 patients who underwent surgical treatment from January 2016 and January 2020 for acetabular fractures involving quadrilateral surface with anterior intrapelvic approach using 105° drill attachment and a minimum of 12 months of postoperative follow-up were included. Perioperative complications, operation duration, and the quality of reduction were evaluated. Reduction quality was classified as poor, imperfect, and anatomic. Functional evaluation was performed according to the Harris Hip Score (HHS) and Merle d'Aubigne Score.

RESULTS

Among 35 patients (median age 36 (21-80)), radiological results of the acetabular fixations were anatomic, imperfect, and poor in 28 (80%), 5 (14.3%), and 2 (5.7%) patients, respectively. Postoperative 1-year functional outcomes with Merle d'Aubigne scores and HHS were median 18 (10-18) and 90 (60-96), respectively. The clinical outcomes of the patients showed concordance with reduction quality. The median operation duration was 180 minutes (range 125-270). Iatrogenic neurovascular damage was not noted in any patients.

DISCUSSION

Reduction and fixation of deep intrapelvic fractures are risky and difficult due to the narrow anatomy and adjacent crucial neurovascular structures. As the 105-degree drill application is safe and easy to intervene in, short surgery duration and satisfactory results with minimum complications can be obtained with a 105 angulated drill in the deep pelvic region.

摘要

背景

本研究旨在探讨使用 105°钻头在前盆内入路治疗累及四边体的髋臼骨折的影像学和功能结果。

方法

纳入 2016 年 1 月至 2020 年 1 月期间因累及四边体的髋臼骨折在前盆内入路中使用 105°钻头并接受至少 12 个月术后随访的 35 例患者。评估围手术期并发症、手术时间和复位质量。复位质量分为差、不完美和解剖复位。根据 Harris 髋关节评分(HHS)和 Merle d'Aubigne 评分进行功能评估。

结果

35 例患者(中位数年龄 36 岁[21-80 岁])中,28 例(80%)、5 例(14.3%)和 2 例(5.7%)患者的髋臼固定影像学结果分别为解剖复位、不完美复位和差复位。术后 1 年 Merle d'Aubigne 评分和 HHS 的功能结果中位数分别为 18(10-18)和 90(60-96)。患者的临床结果与复位质量一致。手术时间中位数为 180 分钟(范围 125-270 分钟)。术中未发生医源性神经血管损伤。

讨论

由于骨盆深部解剖结构狭窄,毗邻重要的神经血管结构,因此深部骨盆骨折的复位和固定具有一定风险和难度。由于 105°钻头应用安全,易于干预,因此在骨盆深部使用 105°角钻头可获得较短的手术时间和最小并发症的满意结果。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/6c66/10390178/8e81519de02d/turkjmedsci-52-3-816f1.jpg
