Düsenberg Björn, Esper Julian D, Maußner Felix, Mayerhofer Magdalena, Schmidt Jochen, Peukert Wolfgang, Bück Andreas
Institute of Particle Technology, Friedrich-Alexander-Universität Erlangen-Nürnberg, Cauerstraße 4, D-91058 Erlangen, Germany.
Collaborative Research Center 814-Additive Manufacturing (DFG, German Research Foundation), Am Weichselgarten 9, D-91058 Erlangen, Germany.
Polymers (Basel). 2022 Oct 27;14(21):4555. doi: 10.3390/polym14214555.
Polymer composites and blend systems are of increasing importance, due to the combination of unique and different material properties. Blending polybutylene terephthalate (PBT) with polycarbonate (PC) has been the focus of attention for some time in order to combine thermo-chemical with mechanical resistance. The right compounding of the two polymers is a particular challenge, since phase boundaries between PBT and PC lead to coalescence during melting, and thus to unwanted segregation within the composite material. Amorphization of the semi-crystalline PBT would significantly improve the blending of the two polymers, which is why specific miscibility aids are needed for this purpose. Recent research has focused on the functionalization of polymers with shape-anisotropic glass particles. The advantage of those results from their two-dimensional shape, which not only improves the mechanical properties but are also suspected to act as miscibility aids, as they could catalyze transesterification or act as crystallization modifier. This work presents a process route for the production of PBT-PC blends via co-comminution and an in-situ additivation of the polymer blend particles with anisotropic glass flakes to adjust the crystallinity and therefore enhance the miscibility of the polymers.
由于独特且不同的材料特性相结合,聚合物复合材料和共混体系变得越来越重要。一段时间以来,将聚对苯二甲酸丁二醇酯(PBT)与聚碳酸酯(PC)共混一直是关注的焦点,目的是将热化学抗性与机械抗性结合起来。两种聚合物的正确混合是一项特殊挑战,因为PBT和PC之间的相界在熔融过程中会导致聚结,从而在复合材料中产生不希望的偏析。半结晶PBT的非晶化将显著改善两种聚合物的混合,这就是为此需要特定的增容剂的原因。最近的研究集中在使用形状各向异性玻璃颗粒对聚合物进行功能化。这些颗粒的优势源于其二维形状,这不仅改善了机械性能,还被怀疑可作为增容剂,因为它们可以催化酯交换反应或作为结晶改性剂。这项工作提出了一种通过共粉碎以及用各向异性玻璃薄片对聚合物共混颗粒进行原位添加来生产PBT-PC共混物的工艺路线,以调节结晶度,从而提高聚合物的混溶性。
