Track-before-Detect Algorithm for Underwater Diver Based on Knowledge-Aided Particle Filter.

This work studies the underwater detection and tracking of diver targets under a low signal-to-reverberation ratio (SRR) in active sonar systems. In particular, a particle filter track-before-detect based on a knowledge-aided (KA-PF-TBD) algorithm is proposed. Specifically, the original echo data is directly used as the input of the algorithm, which avoids the information loss caused by threshold detection. Considering the prior motion knowledge of the underwater diver target, we established a multi-directional motion model as the state transition model. An efficient method for calculating the statistical characteristics of echo data about the extended target is proposed based on the non-parametric kernel density estimation theory. The multi-directional movement model set and the statistical characteristics of the echo data are used as the knowledge-aided information of the particle filter process: this is used to calculate the particle weight with the sub-area instead of the whole area, and then the particles with the highest weight are used to estimate the target state. Finally, the effectiveness of the proposed algorithm is proved by simulation and sea-level experimental data analysis through joint evaluation of detection and tracking performance.
