使用逻辑推导序列串联质谱法对N-聚糖异构体进行结构鉴定。
Structural identification of N-glycan isomers using logically derived sequence tandem mass spectrometry.
作者信息
Liew Chia Yen, Yen Chu-Chun, Chen Jien-Lian, Tsai Shang-Ting, Pawar Sujeet, Wu Chung-Yi, Ni Chi-Kung
机构信息
Institute of Atomic and Molecular Sciences, Academia Sinica, Taipei, Taiwan.
International Graduate Program of Molecular Science and Technology, National Taiwan University, Taipei, Taiwan.
出版信息
Commun Chem. 2021 Jun 17;4(1):92. doi: 10.1038/s42004-021-00532-z.
N-linked glycosylation is one of the most important protein post-translational modifications. Despite the importance of N-glycans, the structural determination of N-glycan isomers remains challenging. Here we develop a mass spectrometry method, logically derived sequence tandem mass spectrometry (LODES/MS), to determine the structures of N-glycan isomers that cannot be determined using conventional mass spectrometry. In LODES/MS, the sequences of successive collision-induced dissociation are derived from carbohydrate dissociation mechanisms and apply to N-glycans in an ion trap for structural determination. We validate LODES/MS using synthesized N-glycans and subsequently applied this method to N-glycans extracted from soybean, ovalbumin, and IgY. Our method does not require permethylation, reduction, and labeling of N-glycans, or the mass spectrum databases of oligosaccharides and N-glycan standards. Moreover, it can be applied to all types of N-glycans (high-mannose, hybrid, and complex), as well as the N-glycans degraded from larger N-glycans by any enzyme or acid hydrolysis.
N-连接糖基化是最重要的蛋白质翻译后修饰之一。尽管N-聚糖很重要,但N-聚糖异构体的结构测定仍然具有挑战性。在这里,我们开发了一种质谱方法,即逻辑推导序列串联质谱法(LODES/MS),以确定使用传统质谱法无法确定的N-聚糖异构体的结构。在LODES/MS中,连续碰撞诱导解离的序列源自碳水化合物解离机制,并应用于离子阱中的N-聚糖以进行结构测定。我们使用合成的N-聚糖验证了LODES/MS,随后将该方法应用于从大豆、卵清蛋白和IgY中提取的N-聚糖。我们的方法不需要对N-聚糖进行全甲基化、还原和标记,也不需要寡糖和N-聚糖标准品的质谱数据库。此外,它可以应用于所有类型的N-聚糖(高甘露糖型、杂合型和复合型),以及通过任何酶或酸水解从较大的N-聚糖降解而来的N-聚糖。
