经口胆管镜检查术中使用红色双色成像识别胆管活检后的出血点:一例报告

Identification of bleeding points after bile duct biopsy using red dichromatic imaging during peroral cholangioscopy: A case report.

作者信息

Kimura Yusuke, Okano Naoki, Hoshi Kensuke, Iwata Shuntaro, Ujita Wataru, Yamada Yuto, Iwasaki Susumu, Takuma Kensuke, Ito Ken, Igarashi Yoshinori, Matsuda Takahisa

机构信息

Division of Gastroenterology and Hepatology Toho University Omori Medical Center Tokyo Japan.

出版信息

DEN Open. 2023 Feb 22;3(1):e215. doi: 10.1002/deo2.215. eCollection 2023 Apr.

Abstract

Red dichromatic imaging is a new image-enhancement technology that clarifies the differences in blood concentrations and improves the visibility of the bleeding point. A 71-year-old man was presented with a common bile duct stone, which was completely removed using electrohydraulic shock wave lithotripsy with peroral cholangioscopy. During peroral cholangioscopy, a nodular lesion was found at the confluence of the cystic duct, and a forceps biopsy was performed. It was difficult to confirm the bleeding point using white-light imaging because of the pooling of blood. After switching to red dichromatic imaging mode 2 and washing the bile duct with saline solution, the bleeding point was observed in darker yellow than the surrounding blood, allowing the identification of the bleeding point. Red dichromatic imaging can be used in the future to maintain hemostasis during peroral cholangioscopy.

摘要

红色双色成像技术是一种新型图像增强技术,可清晰显示血液浓度差异,提高出血点的可视性。一名71岁男性患者被诊断为胆总管结石,通过经口胆管镜下的电液压冲击波碎石术将结石完全清除。在经口胆管镜检查过程中,在胆囊管汇合处发现一个结节性病变,并进行了钳取活检。由于血液积聚,使用白光成像难以确认出血点。切换到红色双色成像模式2并用生理盐水冲洗胆管后,观察到出血点呈现出比周围血液更深的黄色,从而得以识别出血点。未来,红色双色成像技术可用于经口胆管镜检查期间的止血操作。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5fe5/9947457/6e9322a11f38/DEO2-3-e215-g002.jpg
