Bansal Swati, Jain Rajiv, Budhiraja Virendra, Swami Shveta, Gupta Rimpi
Department of Anatomy, Kalpana Chawla Government Medical College, Karnal, India.
Department of Medicine, Nemi Chand Medical College, Israna, India.
Anat Cell Biol. 2023 Jun 30;56(2):205-210. doi: 10.5115/acb.22.240. Epub 2023 Apr 13.
Left coronary artery divides into anterior interventricular branch and circumflex branch. As both the arteries run in their corresponding grooves, an arteriovenous trigone is formed between conus arteriosus and left auricle called triangle of Brocq and Mouchet. The triangle base is formed by great cardiac vein. This study aims to describe the frequency of triangle and its type and relationship between various boundaries and content of triangle and to supplement the existing knowledge of clinicians. This observational and descriptive study was conducted on 40 formalin fixed cadaveric hearts in department of anatomy, Kalpana chawla government medical college. The triangle was found in 92.5% of specimen with most common type being closed (51.3%) which is followed by inferiorly open in 35.1%, superiorly open in 8.1% and completely open in 5.4% hearts. Most frequent content of triangle was median artery followed by diagonal branches of anterior interventricular and circumflex branches. The mean area of the triangle was 246.3 mm. Relationship of vein with two arterial branches was either superficial or deep. The knowledge of different patterns of existence will be required for angiographic procedures. Further the triangle is a potential epicardial access route to left fibrous ring. Thus detailed knowledge of variations will help cardiologist to achieve better outcome in interventional procedures with minimal complications.
左冠状动脉分为前室间支和旋支。由于这两条动脉都走行于各自相应的沟内,在动脉圆锥和左心耳之间形成了一个动静脉三角,称为布罗克和穆谢三角。该三角的底部由心大静脉构成。本研究旨在描述该三角的出现频率、类型以及三角各边界与内容物之间的关系,以补充临床医生现有的知识。这项观察性和描述性研究在卡尔帕娜·乔拉政府医学院解剖学系的40颗经福尔马林固定的尸体心脏上进行。在92.5%的标本中发现了该三角,最常见的类型是闭合型(51.3%),其次是下开口型(35.1%)、上开口型(8.1%)和完全开口型(5.4%)。该三角最常见的内容物是中间动脉,其次是前室间支和旋支的对角支。该三角的平均面积为246.3平方毫米。静脉与两条动脉分支的关系为浅位或深位。血管造影操作需要了解不同的存在模式。此外,该三角是通向左纤维环的潜在的心外膜入路。因此,详细了解变异情况将有助于心脏病专家在介入手术中获得更好的结果,同时将并发症降至最低。
