College of Physics and Electronic Information, Yunnan Normal University, Kunming 650000, China.
Kunming Institute of Physics, Kunming 650223, China.
Sensors (Basel). 2023 Apr 10;23(8):3862. doi: 10.3390/s23083862.
It is important to obtain information on an instantaneous target. A high-speed camera can capture a picture of an immediate scene, but spectral information about the object cannot be retrieved. Spectrographic analysis is a key tool for identifying chemicals. Detecting dangerous gas quickly can help ensure personal safety. In this paper, a temporally and spatially modulated long-wave infrared (LWIR)-imaging Fourier transform spectrometer was used to realize hyperspectral imaging. The spectral range was 7001450 cm (714.5 μm). The frame rate of infrared imaging was 200 Hz. The muzzle-flash area of guns with calibers of 5.56 mm, 7.62 mm, and 14.5 mm were detected. LWIR images of muzzle flash were obtained. Spectral information on muzzle flash was obtained using instantaneous interferograms. The main peak of the spectrum of the muzzle flash appeared at 970 cm (10.31 μm). Two secondary peaks near 930 cm (10.75 μm) and 1030 cm (9.71 μm) were observed. Radiance and brightness temperature were also measured. The spatiotemporal modulation of the LWIR-imaging Fourier transform spectrometer provides a new method for rapid spectral detection. The high-speed identification of hazardous gas leakage can ensure personal safety.
获取瞬时目标的信息非常重要。高速相机可以拍摄即时场景的照片,但无法获取物体的光谱信息。光谱分析是识别化学物质的关键工具。快速检测危险气体有助于确保个人安全。本文采用时间和空间调制的长波红外(LWIR)成像傅里叶变换光谱仪实现了高光谱成像。光谱范围为 7001450 cm(714.5 μm)。红外成像的帧率为 200 Hz。检测了 5.56 毫米、7.62 毫米和 14.5 毫米口径枪支的枪口闪光区域。获得了枪口闪光的 LWIR 图像。使用瞬时干涉图获得了枪口闪光的光谱信息。枪口闪光光谱的主峰出现在 970 cm(10.31 μm)处。观察到两个近 930 cm(10.75 μm)和 1030 cm(9.71 μm)的次峰。还测量了辐亮度和亮度温度。LWIR-成像傅里叶变换光谱仪的时空调制为快速光谱检测提供了一种新方法。危险气体泄漏的高速识别可以确保个人安全。
