Pharmaceutical Analytical Chemistry Department, Faculty of Pharmacy, Ain Shams University, Cairo, 11566, Egypt.
Pharmaceutical Analytical Chemistry Department, Faculty of Pharmacy, Cairo University, Cairo, 11562, Egypt.
Anal Bioanal Chem. 2023 Sep;415(22):5451-5462. doi: 10.1007/s00216-023-04818-0. Epub 2023 Jun 30.
One of the most important reasons for an increased mortality rate of cancer is late diagnosis. Point-of-care (POC) diagnostic sensors can provide rapid and cost-effective diagnosis and monitoring of cancer biomarkers. Portable, disposable, and sensitive sarcosine solid-contact ion-selective potentiometric sensors (SC-ISEs) were fabricated as POC analyzers for the rapid determination of the prostate cancer biomarker sarcosine. Tungsten trioxide nanoparticles (WO NPs), polyaniline nanoparticles (PANI NPs), and PANI-WO nanocomposite were used as ion-to-electron transducers on screen-printed sensors. WO NPs and PANI-WO nanocomposite have not been investigated before as ion-to-electron transducer layers in potentiometric SC sensors. The designated sensors were characterized using SEM, XRD, FTIR, UV-VIS spectroscopy, and EIS. The inclusion of WO and PANI in SC sensors enhanced the transduction at the interface between the screen-printed SC and the ion-selective membrane, offering lower potential drift, a longer lifetime, shorter response time, and better sensitivity. The proposed sarcosine sensors exhibited Nernstian slopes over linear response ranges 10-10 M, 10-10 M, 10-10 M, and 10-10 M for control, WO NPs, PANI NPs, and PANI-WO nanocomposite-based sensors, respectively. From a comparative point of view between the four sensors, PANI-WO nanocomposite inclusion offered the lowest potential drift (0.5 mV h), the longest lifetime (4 months), and the best LOD (9.95 × 10 M). The proposed sensors were successfully applied to determine sarcosine as a potential prostate cancer biomarker in urine without prior sample treatment steps. The WHO ASSURED criteria for point-of-care diagnostics are met by the proposed sensors.
癌症死亡率上升的一个最重要原因是诊断较晚。即时检测(POC)诊断传感器可以提供快速且具有成本效益的癌症生物标志物诊断和监测。便携式、一次性和灵敏的肌氨酸固体接触离子选择性电位传感器(SC-ISE)被制作为 POC 分析仪,用于快速测定前列腺癌生物标志物肌氨酸。三氧化钨纳米粒子(WO NPs)、聚苯胺纳米粒子(PANI NPs)和 PANI-WO 纳米复合材料被用作丝网印刷传感器上的离子-电子转换器。WO NPs 和 PANI-WO 纳米复合材料以前尚未作为电位 SC 传感器中的离子-电子换能器层进行过研究。指定的传感器使用 SEM、XRD、FTIR、UV-VIS 光谱和 EIS 进行了表征。在 SC 传感器中加入 WO 和 PANI 增强了丝网印刷 SC 与离子选择性膜之间的界面转换,提供了更低的电位漂移、更长的寿命、更短的响应时间和更好的灵敏度。所提出的肌氨酸传感器在 10-10 M、10-10 M、10-10 M 和 10-10 M 的线性响应范围内表现出 Nernstian 斜率,分别为对照、WO NPs、PANI NPs 和 PANI-WO 纳米复合材料基传感器。从四个传感器的比较角度来看,PANI-WO 纳米复合材料的包含提供了最低的电位漂移(0.5 mV h)、最长的寿命(4 个月)和最佳的 LOD(9.95×10-10 M)。所提出的传感器无需样品预处理步骤,成功地用于测定尿液中的肌氨酸作为潜在的前列腺癌生物标志物。所提出的传感器符合即时诊断的 WHO ASSURED 标准。
