冠状动脉 CTA 检测斑块的准确性和局限性:与光学相干断层成像术的节段比较。

Accuracy and limitation of plaque detection by coronary CTA: a section-to-section comparison with optical coherence tomography.

机构信息

Department of Cardiology, St Francis Hospital and Heart Center, 100 Port Washington Blvd, Roslyn, NY, USA.

Department of Cardiology, Shanghai Chest Hospital, Shanghai Jiaotong University School of Medicine, Shanghai, China.

出版信息

Sci Rep. 2023 Jul 22;13(1):11845. doi: 10.1038/s41598-023-38675-9.


DOI:10.1038/s41598-023-38675-9
PMID:37481671
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC10363114/
Abstract

Plaques identified by Coronary CT angiography (CCTA) are important in clinical diagnosis and primary prevention. High-risk plaque features by CCTA have been extensively validated using optical coherence tomography (OCT). However, since their general diagnostic performance and limitations have not been fully investigated, we sought to compare CCTA with OCT among consecutive vessel sections. We retrospectively compared 188 consecutive plaques and 84 normal sections in 41 vessels from 40 consecutive patients referred for chest pain evaluation who had both CCTA and OCT with a median time lapse of 1 day. The distance to reference points were used to co-register between the modalities and the diagnostic performance of CCTA was evaluated against OCT. Plaque categories evaluated by CT were calcified, non-calcified and mixed. The diagnostic performance of CCTA was excellent for detecting any plaque identified by OCT with the sensitivity, specificity, negative and positive predictive values and accuracy of 92%, 98%, 99%, 84% and 93%, respectively. The lower than expected negative predictive value was due to failure of detecting sub-millimeter calcified (≤ 0.25 mm) (N = 12) and non-calcified plaques (N = 4). Misclassification of plaque type accounted for majority of false negative findings (25/41, 61%) which was most prevalent among the mixed plaque (19/41, 46%). There was calcification within mixed plaques (N = 5) seen by CCTA but missed by OCT. Our findings suggest that CCTA is excellent at identifying coronary plaques except those sub-millimeter in size which likely represent very early atherosclerosis, although the clinical implication of very mild atherosclerosis is yet to be determined.

摘要

冠状动脉 CT 血管造影 (CCTA) 识别的斑块在临床诊断和一级预防中很重要。CCTA 广泛验证了高危斑块特征,采用的是光学相干断层扫描 (OCT)。然而,由于它们的一般诊断性能和局限性尚未得到充分研究,我们试图比较 CCTA 和 OCT 在连续血管节段中的表现。我们回顾性比较了 40 例连续胸痛患者的 41 个血管中的 188 个连续斑块和 84 个正常节段,CCTA 和 OCT 的中位时间间隔为 1 天。使用参考点之间的距离在模态之间进行配准,并根据 OCT 评估 CCTA 的诊断性能。CT 评估的斑块类别包括钙化、非钙化和混合斑块。CCTA 检测 OCT 识别的任何斑块的诊断性能均非常出色,其敏感性、特异性、阴性预测值、阳性预测值和准确性分别为 92%、98%、99%、84%和 93%。低于预期的阴性预测值是由于未能检测到亚毫米钙化(≤0.25mm)(N=12)和非钙化斑块(N=4)。斑块类型的错误分类导致了大部分假阴性发现(25/41,61%),这在混合斑块中最为常见(19/41,46%)。CCTA 可见混合斑块(N=5)中有钙化,但 OCT 漏诊。我们的研究结果表明,CCTA 非常擅长识别冠状动脉斑块,除了那些亚毫米大小的斑块,这些斑块可能代表非常早期的动脉粥样硬化,尽管非常轻度动脉粥样硬化的临床意义尚未确定。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/35fe0ca576a4/41598_2023_38675_Fig6_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/893cc591a599/41598_2023_38675_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/8e691b7891e8/41598_2023_38675_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/436a7f538383/41598_2023_38675_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/b49a00ec244a/41598_2023_38675_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/cef997ccba77/41598_2023_38675_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/35fe0ca576a4/41598_2023_38675_Fig6_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/893cc591a599/41598_2023_38675_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/8e691b7891e8/41598_2023_38675_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/436a7f538383/41598_2023_38675_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/b49a00ec244a/41598_2023_38675_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/cef997ccba77/41598_2023_38675_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c82c/10363114/35fe0ca576a4/41598_2023_38675_Fig6_HTML.jpg
