用于PLC窄带应用的带有PCB HDI罗戈夫斯基线圈的干扰电平检测器。

Interference Level Detector with PCB HDI Rogowski coil for PLC Narrow-Band Applications.

作者信息

Lisowiec Aleksander, Habrych Marcin, Michalski Pawel, Miedzinski Bogdan, Wisniewski Grzegorz

机构信息

Łukasiewicz Research Network-Tele & Radio Research Institute, Ratuszowa St. 11, 03-450 Warsaw, Poland.

Faculty of Electrical Engineering, Wroclaw University of Science and Technology, Wybrzeze Wyspianskiego St. 27, 50-370 Wroclaw, Poland.

出版信息

Sensors (Basel). 2023 Jul 26;23(15):6682. doi: 10.3390/s23156682.

DOI:10.3390/s23156682

PMID:37571469

原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC10422471/

Abstract

This article presents and discusses the structure, principle of operation, and operational properties of a newly developed interference level detector (ILD) designed to measure conducted supraharmonic disturbances (1-150 kHz) in the power grid and to assess the effectiveness of narrow-band Power Line Communication (PLC) transmission, especially in the PRIME technology. The usability assessment was made on the basis of the validation and the results of tests carried out in a low-voltage network with non-linear loads. Appropriate practical conclusions were then formulated.

摘要

本文介绍并讨论了一种新开发的干扰电平检测器（ILD）的结构、工作原理和运行特性，该检测器旨在测量电网中的传导超谐波干扰（1 - 150 kHz），并评估窄带电力线通信（PLC）传输的有效性，特别是在PRIME技术中的有效性。基于在带有非线性负载的低压网络中进行的验证和测试结果进行了可用性评估。然后得出了适当的实际结论。
