Department of Obstetrics and Gynecology, Ewha Womans University College of Medicine, Ewha Womans University Seoul Hospital, Seoul 07804, Republic of Korea.
Medicina (Kaunas). 2023 Jul 28;59(8):1387. doi: 10.3390/medicina59081387.
: VACTERL association is a widely known congenital malformation that includes vertebral, anal, cardiac, tracheoesophageal, renal, and limb anomalies. Patients with VACTERL and hydrocephalus appear to form a distinct group, both genetically and phenotypically, and their condition has been called VACTERL-H syndrome. Most cases of VACTERL-H have been reported postnatally, as VACTER-H syndrome is difficult to diagnose prenatally. Here, we report a case of VACTERL-H syndrome in a dichorionic and diamniotic twin diagnosed prenatally by ultrasonography and confirmed postnatally by three-dimensional computed tomography (3D CT). A 34-year-old multiparous female was referred to our institution at 31 + 3 weeks gestation for suspected fetal ventriculomegaly. Detailed examinations using two-dimensional and Doppler ultrasounds revealed hydrocephalus, bilateral dysplastic upper arms, radial aplasia, unilateral pulmonary agenesis, dextrocardia with right atrial enlargement, a unilateral hypoplastic ectopic kidney, a single umbilical artery, a tracheoesophageal fistula with a small stomach, polyhydramnios, and anal atresia. Findings from the postnatal 3D CT aligned with the prenatal diagnosis, showing upper-limb agenesis, dextrocardia with pulmonary hypoplasia, tracheoesophageal fistula, imperforate anus, and colon dilatation. The affected 1390-g male twin had an unaffected 1890-g female twin sister and a healthy 6-year-old brother. : Upon encountering fetuses with multiple anomalies, including ventriculomegaly, a small stomach with polyhydramnios, an abnormally positioned heart, and upper-limb abnormalities, clinicians should perform systematic ultrasonographic examinations to detect associated anomalies and be aware of VACTERL-H syndrome.
VACTERL 协会是一种广为人知的先天性畸形,包括脊柱、肛门、心脏、气管食管、肾脏和肢体异常。患有 VACTERL 和脑积水的患者似乎在遗传和表型上形成了一个独特的群体,他们的病情被称为 VACTERL-H 综合征。大多数 VACTERL-H 病例都是在产后报告的,因为 VACTERL-H 综合征很难在产前诊断。在这里,我们报告了一例产前通过超声诊断并通过三维 CT 产后证实的双绒毛膜和双羊膜性双胞胎 VACTERL-H 综合征病例。一位 34 岁的多产妇在 31+3 周妊娠时因疑似胎儿脑室扩大被转诊至我们机构。使用二维和多普勒超声进行的详细检查显示脑积水、双侧发育不良的上臂、桡骨发育不全、单侧肺发育不全、右心房扩大的右位心、单侧发育不良的异位肾、单脐动脉、伴有小胃的气管食管瘘、羊水过多和肛门闭锁。产后的 3D CT 检查结果与产前诊断一致,显示上肢发育不全、肺发育不全的右位心、气管食管瘘、肛门闭锁和结肠扩张。受影响的 1390 克男性双胞胎有一个未受影响的 1890 克女性双胞胎妹妹和一个健康的 6 岁弟弟。
当遇到伴有脑室扩大、羊水过多的小胃、心脏位置异常和上肢异常等多种畸形的胎儿时,临床医生应进行系统的超声检查,以发现相关畸形,并警惕 VACTERL-H 综合征。
