A Simple, Lightweight, and Low-Cost Customizable Multielectrode Array for Local Field Potential Recordings.

Local field potential (LFP) recording is a valuable method for assessing brain systems communication. Multiple methods have been developed to collect LFP data to study the rhythmic activity of the brain. These methods range from the use of single or bundled metal electrodes to electrode arrays that can target multiple brain regions. Although these electrodes are efficient in collecting LFP activity, they can be expensive, difficult to build, and less adaptable to different applications, which may include targeting multiple brain regions simultaneously. Here, the building process for a 16-channel customizable multielectrode array (CMEA) that can be used to collect LFP data from different brain regions simultaneously in rats is described. These CMEA electrode arrays are lightweight (<1 g), take little time to build (<1 h), and are affordable ($15 Canadian). The CMEA can also be modified to record single-unit and multiunit activity in addition to LFP activity using both wired and wireless neural data acquisition systems. Moreover, these CMEAs can be used to explore neural activity (LFP and single-unit/multiunit activity) in preliminary studies, before purchasing more expensive electrodes for targeted studies. Together, these characteristics make the described CMEA a competitive alternative to the commercially available multielectrode arrays for its simplicity, low cost, and efficiency in collecting LFP data in freely behaving animals.
