Gad Ehab S, Abbas Mohamed A, Bedair Mahmoud A, El-Azabawy Olfat E, Mukhtar Shymaa M
Chemistry Department, College of Science and Arts, Jouf University, Alqurayat, Saudi Arabia.
Egyptian Petroleum Research Institute (EPRI), Cairo, 11727, Egypt.
Sci Rep. 2023 Sep 12;13(1):15091. doi: 10.1038/s41598-023-41165-7.
The studied Schiff-base compounds in this work are multitasked investigated as corrosion inhibitors and also, to improve the physical and mechanical properties of reinforced concrete. The efficiency inhibition of the two novel Schiff-base compounds named (DHSiMF) and (DHSiB) for corrosion of carbon-steel in aqueous media of 1 M HCl was assessed via electrochemical methods and loss in weight. FT-IR, H-NMR spectra and elemental analysis were used to confirm the structure of such compounds. It was found to have successful inhibition even at low concentrations in tested media, as an increase in inhibitor concentration led to an improvement in the inhibition efficiency. The weight loss results clearly demonstrate that DHSiMF of C-steel in 1 M HCl has a higher inhibition efficiency than DHSiB, with a maximum inhibition efficiency (85%) attained at 1 × 10 M from DHSiMF. Electrochemical experiments likewise revealed the same order, but with a maximal inhibitory efficiency of 98.1%. The addition of inhibitors to the corrosive media dramatically changed the anodic Tafel constants (β) and cathodic Tafel constants (β), indicating a mixed type nature. Electrochemical polarization curves illustrated the functions of mixed-type inhibition and the action of adsorption matching with the Langmuir adsorption isotherm. The ∆G values for DHSiMF and DHSiB at temperatures (ranging from 303 to 333 K) are - 34.42 kilojoule/mole to - 37.51 kilojoule/mole. These values indicate that the compounds' adsorption types are chemo-physical adsorption. X-ray diffraction (XRD) and Scanning electron microscopy (SEM) experiments were used to check the existence of the protection layer on the surface of carbon steel by analyzing the morphologies of the corrosion effects and the formed chemical compositions of the corrosion outcomes. For the concrete, the findings suggest that the chemical reaction that takes place between the DHSiMF and DHSiB and the concrete mix will result in an increase in the flexural strength, the compressive strength, and the indirect tensile strength of the concrete that is made of the gravel and dolomite aggregate.
本研究中的席夫碱化合物具有多种功能,既作为缓蚀剂进行了多方面研究,又用于改善钢筋混凝土的物理和力学性能。通过电化学方法和失重法评估了两种新型席夫碱化合物(DHSiMF)和(DHSiB)在1 M HCl水溶液介质中对碳钢腐蚀的缓蚀效率。利用傅里叶变换红外光谱(FT-IR)、氢核磁共振光谱(H-NMR)和元素分析来确认这些化合物的结构。结果发现,即使在测试介质中低浓度时它们也具有成功的缓蚀效果,随着缓蚀剂浓度的增加,缓蚀效率提高。失重结果清楚地表明,在1 M HCl中,DHSiMF对碳钢的缓蚀效率高于DHSiB,DHSiMF在1×10⁻³ M时达到最大缓蚀效率(85%)。电化学实验同样显示了相同的顺序,但最大缓蚀效率为98.1%。向腐蚀介质中添加缓蚀剂显著改变了阳极塔菲尔常数(βa)和阴极塔菲尔常数(βc),表明其为混合型缓蚀剂。电化学极化曲线说明了混合型缓蚀作用以及与朗缪尔吸附等温线相匹配的吸附作用。在温度范围为303至333 K时,DHSiMF和DHSiB的∆G值为-34.42千焦/摩尔至-37.51千焦/摩尔。这些值表明化合物的吸附类型为化学物理吸附。通过X射线衍射(XRD)和扫描电子显微镜(SEM)实验来分析腐蚀效应的形态和腐蚀产物的化学成分,从而检查碳钢表面保护层的存在情况。对于混凝土,研究结果表明,DHSiMF和DHSiB与混凝土混合料之间发生的化学反应将导致由砾石和白云石骨料制成的混凝土的抗弯强度、抗压强度和间接抗拉强度增加。
