Virus-like particles (VLPs) are nanostructures with the potential to present heterologous peptides at high density, thereby triggering heightened immunogenicity. RNA bacteriophage MS2 VLPs are a compelling delivery platform among them. However, a notable hurdle arises from the immune response toward MS2 coat protein, swiftly eliminating subsequent vaccinations via the same vector. Although larger inserts effectively mask carrier epitopes, current research predominantly focuses on displaying short conserved peptides (<30 aa). A systematic evaluation regarding the deterministic ability of MS2 VLPs as a platform for presenting heterologous peptides remains a gap. In light of this, we employed the "single-chain dimer" paradigm to scrutinize the tolerance of MS2 VLPs for peptide/protein insertions. The results unveiled functional MS2 VLP assembly solely for inserts smaller than 91 aa. Particularly noteworthy is the largest insertion achieved on the MS2 VLPs to date: the RNA helicase A (RHA) dsRNA-binding domains (dsRBD1). Attempts to introduce additional linkers or empty coat subunits fail to augment the expression level or assembly of the MS2 VLPs displaying dsRBD1, affirming 91 aa as the upper threshold for exogenous protein presentation. By illuminating the precise confines of MS2 VLPs in accommodating distinct peptide lengths, our study informs the selection of appropriate peptide and protein dimensions. This revelation not only underscores the scope of MS2 VLPs but also establishes a pivotal reference point, facilitating the strategic manipulation of MS2 VLPs to design next-generation epitope/antibody-based therapeutics.
