Modeling of a Broadband Microwave Composite Thin Film Absorber.

Composite thin film absorbers show superior performance and have a wide range of applications. Obtaining a broadband composite thin film absorber is a challenge. In this work, we proposed a modeling of a broadband microwave composite thin film absorber based on the impedance matching theory and equivalent circuit model of the square loop. The unit cell of the absorber was composed of metal square loops with high magnetic conductivity deposited on the polyethylene substrate, and an FR-4 (epoxy glass cloth) substrate was the spacer substrate layer. The simulation results show that the absorptivity of the absorber reached more than 90% in the frequency range of 8.7-18 GHz for TE and TM waves under normal incidence. The thickness of the designed absorber was 2.05 mm (0.059 λ, λ corresponds to the maximum absorption wavelength). The simulation results show that the energy distribution in the proposed absorber was mainly localized in the top metal FSS layer due to the ohmic loss of metal, and the dielectric loss played a small role in the absorption of the absorber. Our work provides a design approach to improve the efficiency of optoelectronic devices and thermal detectors and has application prospects in radar and aircraft stealth applications.
