Surface Analysis of Stainless Steel Electrodes Cleaned by Atmospheric Pressure Plasma.

The Z-pinch device is a critical component in inertial confinement fusion, where stainless steel electrodes must withstand high current densities of up to MA/cm. Gases and difficult-to-remove impurities adhering to the electrode surfaces can ionize, significantly impacting the device's electrical conductivity efficiency. In this paper, the surface of stainless steel electrodes was subjected to cleaning using a large-area plasma jet under atmospheric pressure. The wettability, chemical composition, and chemical state of the electrode surface were characterized using a water contact angle measuring instrument and X-ray photoelectron spectroscopy (XPS). The cleaning effect under different discharge parameters was systematically analyzed. The results revealed a significant reduction in the content of carbon pollutants on the surface of stainless steel electrodes, decreasing from 62.95% to a minimum of 37.68% after plasma cleaning. Moreover, the water contact angle decreased from 70.76° to a minimum of 29.31°, and the content of water molecules adsorbed on the surface decreased from 17.31% to a minimum of 5.9%. Based on the evolution process of micro-element content and chemical state on the surface of stainless steel electrode, the cleaning process of adhering substances on the surface by atmospheric pressure plasma was analyzed by the layered cleaning model for surface pollutants on stainless steel.
