Rodríguez-Sanz Jacobo, Malo-Urriés Miguel, Borrella-Andrés Sergio, Albarova-Corral Isabel, López-de-Celis Carlos
Faculty of Medicine and Health Science, Universitat Internacional de Catalunya, 08195 Barcelona, Spain.
ACTIUM Functional Anatomy Group, 08195 Barcelona, Spain.
Diagnostics (Basel). 2025 Feb 6;15(3):389. doi: 10.3390/diagnostics15030389.
While MRI is the gold standard for meniscal assessment, its cost and accessibility limitations have led to growing interest in ultrasound, though its validity for quantifying meniscal tissue remains unclear. To validate the use of ultrasound in quantifying meniscal tissue across the anterior, middle, and posterior regions of both menisci (medial and lateral) in longitudinal and transverse planes by comparison with cadaveric dissection. : A cross-sectional study was conducted on ten cryopreserved anatomical donors, obtaining a total of 120 ultrasound scans from the different meniscal regions. Following ultrasound imaging, cadaveric dissection was performed to facilitate photometric measurements, thereby enabling validation of the ultrasound findings. The intra-examiner reliability of the ultrasound measurements was also assessed. : The intra-examiner reliability of ultrasound measurements ranged from moderate to excellent. A strong and statistically significant positive correlation was observed between ultrasound and photometric measurements across all meniscal regions (r > 0.821; < 0.05). In the medial meniscus, ultrasound visualized 99.1% of the anterior region (8.71 mm with ultrasound; 8.64 mm with photometry), 96.3% of the middle region (9.09 mm with ultrasound; 9.39 mm with photometry), and 98.5% of the posterior region (10.54 mm with ultrasound; 10.61 mm with photometry). In the lateral meniscus, ultrasound visualized 107.1% of the anterior region, 105.1% of the middle region, and 97.8% of the posterior region. The observed excess in tissue visualization in some regions likely reflects the inclusion of adjacent connective tissue, indistinguishable from meniscal tissue on ultrasound. : Ultrasound is a valid and reliable modality for visualizing most meniscal tissue across regions, with a measurement discrepancy under 0.7 mm compared to anatomical dissection. However, caution is advised as adjacent connective tissue may sometimes be misidentified as meniscal tissue during evaluations.
虽然磁共振成像(MRI)是半月板评估的金标准,但其成本和可及性限制促使人们对超声的兴趣日益增加,不过超声在量化半月板组织方面的有效性仍不明确。通过与尸体解剖对比,验证超声在纵向和横向平面上对双侧半月板(内侧和外侧)的前、中、后区域的半月板组织进行量化的应用。:对10名冷冻保存的解剖学供体进行了横断面研究,从不同的半月板区域共获得120次超声扫描。超声成像后,进行尸体解剖以利于光度测量,从而能够验证超声检查结果。还评估了超声测量的检查者内可靠性。:超声测量的检查者内可靠性从中度到优秀不等。在所有半月板区域,超声与光度测量之间均观察到强且具有统计学意义的正相关(r>0.821;<0.05)。在内侧半月板中,超声显示前区的99.1%(超声测量为8.71mm;光度测量为8.64mm),中区的96.3%(超声测量为9.09mm;光度测量为9.39mm),后区的98.5%(超声测量为10.54mm;光度测量为10.61mm)。在外侧半月板中,超声显示前区的107.1%,中区的105.1%,后区的97.8%。在某些区域观察到的组织可视化过量可能反映了相邻结缔组织的包含,在超声上与半月板组织无法区分。:超声是一种有效且可靠的方法,可用于可视化大多数区域的半月板组织,与解剖解剖相比测量差异小于0.7mm。然而,建议谨慎操作,因为在评估过程中相邻结缔组织有时可能被误识别为半月板组织。
