Zeng Yaping, Zhao Le, Zhang Jiaming, Li Qiuping, Sun Dan, Ren Yu, Tang Yougen, Jin Guanhua, Wang Haiyan
Hunan Provincial Key Laboratory of Chemical Power Sources College of Chemistry and Chemical Engineering Central South University Changsha 410083 P. R. China.
Jiangsu Yeeli Technology Co., Ltd. Wuxi 214200 P. R. China.
Small Sci. 2023 Apr 7;3(6):2300017. doi: 10.1002/smsc.202300017. eCollection 2023 Jun.
Polymer solid electrolytes (SEs) with high safety and flexibility are ideal for advanced lithium-metal solid-state batteries (SSBs). Among various polymer SEs, polyvinylidene fluoride-hexafluoropropylene (PVDF-HFP) polymer SEs have gained increased attention for their high dielectric constants, high ionic conductivity, and excellent flexibility. However, severe side reactions at the interface caused by the decomposition of residual DMF solvent significantly reduce the cycle life of PVDF-HFP-based SSBs. Herein, LaO nanoparticles are used as new inorganic fillers to form a PVDF-HFP/LiFSI/LaO-40% composite polymer electrolyte (PVDF-HFP/LaO CPE). Benefiting from the interaction between LaO and -dimethylformamide (DMF) solvent molecules, the cell cycling stability is greatly improved. In addition, the PVDF-HFP/LiFSI solid electrolyte (PVDF-HFP SE) containing 40 wt% LaO has the highest ionic conductivity of 1.33 × 10 S cm at 25 °C. It also exhibits a higher lithium-ion transference number of 0.52 and lower polarization. The PVDF-HFP/LaO CPE here ensures high ionic conductivity and stable interface chemistry in SSB, demonstrating a promising application potential.
具有高安全性和柔韧性的聚合物固体电解质(SEs)是先进锂金属固态电池(SSBs)的理想选择。在各种聚合物SEs中,聚偏氟乙烯-六氟丙烯(PVDF-HFP)聚合物SEs因其高介电常数、高离子电导率和出色的柔韧性而受到越来越多的关注。然而,残留DMF溶剂分解导致的界面处严重副反应显著降低了基于PVDF-HFP的SSBs的循环寿命。在此,LaO纳米颗粒用作新型无机填料,以形成PVDF-HFP/LiFSI/LaO-40%复合聚合物电解质(PVDF-HFP/LaO CPE)。受益于LaO与二甲基甲酰胺(DMF)溶剂分子之间的相互作用,电池循环稳定性得到极大提高。此外,含有40 wt% LaO的PVDF-HFP/LiFSI固体电解质(PVDF-HFP SE)在25°C时具有最高离子电导率,为1.33×10 S cm。它还表现出更高的锂离子迁移数0.52和更低的极化。此处的PVDF-HFP/LaO CPE确保了SSB中的高离子电导率和稳定的界面化学,展现出有前景的应用潜力。
