一种带有嵌套椭圆管的间隙补偿低损耗空心反谐振光纤的设计与数值分析

Design and numerical analysis of a gap-compensated low loss hollow-core antiresonant fiber with nested elliptical tubes.

作者信息

Li Yuemei, Zhang Zhaoyang, Guo Yao, Guo Haobo, Zhang Zhiguo

机构信息

State Key Lab of Information Photonics and Optical Communications, Beijing University of Posts and Telecommunications, Beijing, China.

出版信息

Sci Rep. 2025 Jun 5;15(1):19817. doi: 10.1038/s41598-025-04555-7.

DOI:10.1038/s41598-025-04555-7

PMID:40473735

原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC12141478/

Abstract

In this research, we propose a novel hollow-core anti-resonant fiber structure designed to enhance light confinement and reduce losses. Our simulation results indicate that the LP01 mode loss is reduced to 1.807 × 10⁻⁶ dB/km at a wavelength of 1.52 μm, representing an extremely low confinement loss. Additionally, our model exhibits strong bending resistance, maintaining a bending loss of 4.81 × 10⁻⁵ dB/km at a wavelength of 1.55 μm and a bending radius of 6 cm. The dispersion is also maintained at 1 ± 0.7 ps/(nm·km), ensuring low dispersion characteristics. These features suggest its potential for applications in hollow-core fiber-based low-latency telecommunication systems.

摘要

在本研究中，我们提出了一种新型的空心反谐振光纤结构，旨在增强光限制并降低损耗。我们的模拟结果表明，在波长为1.52μm时，LP01模式损耗降低至1.807×10⁻⁶dB/km，这代表着极低的限制损耗。此外，我们的模型表现出很强的抗弯曲能力，在波长为1.55μm、弯曲半径为6cm时，弯曲损耗保持在4.81×10⁻⁵dB/km。色散也保持在1±0.7ps/(nm·km)，确保了低色散特性。这些特性表明其在基于空心光纤的低延迟电信系统中的应用潜力。
