Karoria Arvind, Singh Mayank Pratap, Dubey Deependra, Gohiya Ashish
Department of Orthopaedics, SRVS Medical College Shivpuri, Madhya Pradesh, India.
Government Medical College (GMC), Datia, Madhya Pradesh, India.
J Orthop Case Rep. 2025 Aug;15(8):345-349. doi: 10.13107/jocr.2025.v15.i08.5990.
The medial midline portal and anterocentral both are not standard portals for ankle arthroscopy, but they provide a wide field of vision.
The aim of this study was to compare anatomical safety between medial midline and anterocentral portal in arthroscopy in respect to the least injury to adjacent structures.
20 cadaveric ankles were dissected and related anatomical structures were measured from anterocentral and medial midline portals.
The dorsalis pedis artery (DPA) was at a mean distance of 10.08 mm, the deep peroneal nerve was at 16.20 mm, the tibialis anterior tendon was at 2.41 mm, and the extensor hallucis longus (EHL) tendon was at 2.62 mm from the medial midline portal. The EHL tendon was injured in two specimens during portal placement. The anterocentral portal was placed at a mean distance of 2.38 mm from the DPA, 7.09 mm from the superficial peroneal nerve, and 4.12 mm from the deep peroneal nerve.
Our study demonstrated that the anterocentral portal is safer than the medial midline portal for ankle arthroscopy. While there is a high risk of tendon injury in the medial midline portal.
内侧中线入路和前中央入路都不是踝关节镜检查的标准入路,但它们能提供广阔的视野。
本研究的目的是比较踝关节镜检查中内侧中线入路和前中央入路在对相邻结构损伤最小方面的解剖学安全性。
解剖20具尸体踝关节,测量从前中央入路和内侧中线入路到相关解剖结构的距离。
从内侧中线入路到足背动脉(DPA)的平均距离为10.08mm,到腓深神经的平均距离为16.20mm,到胫骨前肌腱的平均距离为2.41mm,到拇长伸肌(EHL)肌腱的平均距离为2.62mm。在建立入路过程中,两个标本的EHL肌腱受到损伤。前中央入路到DPA的平均距离为2.38mm,到腓浅神经的平均距离为7.09mm,到腓深神经的平均距离为4.12mm。
我们的研究表明,对于踝关节镜检查,前中央入路比内侧中线入路更安全。而内侧中线入路存在较高的肌腱损伤风险。
